Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Sinotech
-
Voltage:
-
Customized
-
Dimension(L*W*H):
-
4600X1300X1900MM
-
Weight:
-
4000 KG
Quick Details
-
Screw Design:
-
Single-screw
-
Screw L/D Ratio:
-
18
-
Screw Speed (rpm):
-
205 rpm
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Sinotech
-
Voltage:
-
Customized
-
Dimension(L*W*H):
-
4600X1300X1900MM
-
Weight:
-
4000 KG
Disposable Medical Laboratory Hospital Urine Blood Stool Specimen Feces Petri Dish Cup injection moulding machine
Product Description
Sino-tech SElll Series High-performance High speed Thin-wall Injection Molding Machine .
Specially designed for high-speed thin-wall products, multiple-cavity products and relevant civil products in current market. The model is created in accordant with latest national design concept, combining decades of experience in design and manufacture of the company.
1.Higher work efficiency. According to features of injection, optimize and integrate injection, clamping, hydraulic and control units, which has greatly shortened the production cycle.
2.Stricter safety standards. Comply with national mandatory safety standard to guarantee operators' safety.
3.More perfect organization .Frame-type rack design; improve rigidity and strength on the basis of finite element analysis, which has greatly improved rack precision, reduced rack deformation and realized a more stable and smooth operation.
Product Parameters
| Item | 120SElll | |||
| Screw diameter | mm | 35 | 40 | 45 |
| Theoretical shot volume | cc | 192 | 251 | 318 |
| Shot weight (PS) | g | 175 | 229 | 289 |
| Shot weight (PS) | oz | 6.2 | 8.1 | 10.2 |
| Length/Diameter ratio | L/D | 23.4 | 20.5 | 18.2 |
| Injection pressure | MPa | 225 | 172 | 136 |
| Injection rate | cm³ /sec | 93 | 122 | 154 |
| Injection stroke | mm | 200 | ||
| Max. Screw speed | rpm | 205 | ||
| Plasticizing capacity (PS) | g/s | 11.9 | 16.2 | 20 |
| Injection unit force | Ton | 5.7 | ||
| Carriage stroke | mm | 300 | ||
| Clamping force | Ton | 130 | ||
| Max. daylight | mm | 880 | ||
| Clamping stroke | mm | 430 | ||
| Distance btwn. Tie bars | mm | 410*410 | ||
| Min mould dimension | mm | 280*280 | ||
| Mould thickness range | mm | 145-450 | ||
| Ejector force | Ton | 4.1 | ||
| Ejector stroke | mm | 120 | ||
| No. of ejector pins | unit | 5 | ||
| Max. motor power | kW | 13.4 | ||
| System pressure | MPa | 17.5 | ||
| Hydraulic pump capacity | L/min | 72 | ||
| No. of heater zones | unit | 3+1 | ||
| Heater input power | kW | 9.3 | ||
| Ultimate capacity | kw | 23.7 | ||
| Current | A | 32.4 | ||
| Net weight | Ton | 4.16 | ||
| Oil filling capacity | L | 200 | ||
