Quick Details
-
After-sales Service Provided:
-
Online Support
-
Product name:
-
HUAJIE 50L-10000L liquid soap making machine production line
-
Material:
-
304SS;316L
-
Usage:
-
cosmetic, food, chemical
-
Stirrer type:
-
Paddling Stirring
-
Capacity:
-
50-20000L
-
Heating method:
-
Steam&electric
-
Homogenizer:
-
0-3600rpm
-
Machine Type:
-
Mixng Machine
-
Discharge:
-
Butterfly Valve
Quick Details
-
Brand Name:
-
HUAJIE
-
Applicable Industries:
-
COSMETIC, CHEMICAL, FOOD
-
Weight (KG):
-
1000
-
After-sales Service Provided:
-
Online Support
-
Product name:
-
HUAJIE 50L-10000L liquid soap making machine production line
-
Material:
-
304SS;316L
-
Usage:
-
cosmetic, food, chemical
-
Stirrer type:
-
Paddling Stirring
-
Capacity:
-
50-20000L
-
Heating method:
-
Steam&electric
-
Homogenizer:
-
0-3600rpm
-
Machine Type:
-
Mixng Machine
-
Discharge:
-
Butterfly Valve
Product Paramenters
|
Model
|
Effective
|
Stirrring power and speed
|
|
Homogeneous power and speed
|
|
Heating power
|
|
|||||||
|
|
Capcity
|
KW
|
R/MIN
|
KW
|
R/MIN
|
Electric heating
|
Steam heating
|
|||||||
|
PMC-50
|
50
|
0.75
|
0-65
|
3
|
3600
|
6 KW
|
Steam heating
energy save
and
environmental
protection
|
|||||||
|
PMC-100
|
100
|
1.5
|
0-65
|
1.5
|
3600
|
12 KW
|
|
|||||||
|
PMC-150
|
150
|
1.5
|
0-65
|
1.5
|
3600
|
12 KW
|
|
|||||||
|
PMC-200
|
200
|
1.5
|
0-65
|
3
|
3600
|
18 KW
|
|
|||||||
|
PMC-300
|
300
|
1.5
|
0-65
|
3
|
3600
|
18 KW
|
|
|||||||
|
PMC-500
|
500
|
2.2
|
0-65
|
4
|
3600
|
27 KW
|
|
|||||||
|
PMC-1000
|
1000
|
4
|
0-65
|
7.5
|
3600
|
36 KW
|
|
|||||||
|
PMC-1500
|
1500
|
4
|
0-65
|
11
|
3600
|
45 KW
|
|
|||||||
|
PMC-2000
|
2000
|
5.5
|
0-65
|
11
|
3600
|
recommed steam heating
|
|
|||||||
|
PMC-3000
|
3000
|
7.5
|
0-55
|
15
|
3600
|
|
|
|||||||
|
PMC-5000
|
5000
|
11
|
0-55
|
22
|
3600
|
|
|
|||||||
|
The parameters for reference ONLY, all the machines can be customized accordingly.
|
|
|
|
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|||||||
High speed disperser .might mixing and disperse Viscously. Solid and liquid raw material can dissolve material which is hard to dissolve such as AES, AESA LSA during liquid production which can save energy consumption and shorten production the and shorten production period.Main adopts stepless timing device which reduce babble occur under low temperature and high viscosity condition less air bubble will be formed to produce liquid washing products.Finished products can be discharged by Disc-valve or suitable to all liquid wash products.
The all-around wall scraping mixing adopts the frequency converter for speed adjustment, so that high quality products of
different processes according to customer requirements.
The diversified high-speed homogenizer can powerfully mix solid and liquid raw materials and can rapidly dissolve many
indissoluble materials such as AES, AESA, LSA,etc.during the liquid detergent production period.
The pot body is welded by imported three-layer stainless steel plate.the tank body and the pipes adopt mirror polishing, which fully conforms to GMP requirements
According to customer requirement, the tank can heat and cool materials the heating way including steam heating and electric heating.easy to discharge,bottom direct discharge or by transfer pump.
The all-around wall scraping mixing adopts the frequency converter for speed adjustment, so that high quality products of
different processes according to customer requirements.
The diversified high-speed homogenizer can powerfully mix solid and liquid raw materials and can rapidly dissolve many
indissoluble materials such as AES, AESA, LSA,etc.during the liquid detergent production period.
The pot body is welded by imported three-layer stainless steel plate.the tank body and the pipes adopt mirror polishing, which fully conforms to GMP requirements
According to customer requirement, the tank can heat and cool materials the heating way including steam heating and electric heating.easy to discharge,bottom direct discharge or by transfer pump.
Application
|
Daily cosmetic
|
|
|
|
|||
|
shampoo
|
cabomer
|
massage oil
|
hand sanitizer
|
|||
|
liquid soap&hand soap
|
deodorant
|
hair pomade
|
disinfectant
|
|||
|
liquid detergent
|
hotel shampoo
|
oil
|
nail polish
|
|||
|
shower gel
|
pomade
|
floor cleaner
|
household industry liquid
|
|||
|
hair wax
|
petroleum jelly
|
bath oil
|
glass cleaning liquid
|
|||
|
hair removal
|
gel
|
hair care product
|
alcohol
|
|||
|
dishwashing liquid
|
essence oil
|
shave foam
|
dishwash gel
|
|||
|
shoe polish
|
cabomer
|
essential oil
|
shea butter
|
|||
|
food
|
|
|
|
|||
|
syrup
|
pigment
|
sugar
|
yogurt
|
|||
|
honey
|
pet food
|
chocolate
|
milk
|
|||
|
tomato paste
|
mouthwash liquid
|
ketchup
|
juice
|
|||
|
food jam
|
Animal food
|
sauce
|
|
|||
|
chemical
|
|
|
|
|||
|
liquid
|
lubricant oil
|
fertilizer
|
print ink
|
|||
|
herbicide
|
gresse oil
|
paint
|
pesticide
|
|||
