Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
OEM
-
Model Number:
-
EX219
-
Product name:
-
Automatic Door Pedal Switch
-
Technical measure:
-
Active infrared ray of modulation and demodulation
-
Recommend installation height:
-
0.3m height from the ground
-
Reaction time:
-
Relay output <45ms
-
Power supply:
-
AC/DC 12~30V
-
Current:
-
Standby 8.2mA,Operating 47mA
-
Supervisory signal:
-
4.5S MA
-
Signal output:
-
Relay normally open or normally closed
-
Operation temperature:
-
-20℃~55℃
-
Dimension:
-
186x175x53mm
-
Certification:
-
CE
Quick Details
-
Protection Level:
-
IP55
-
Max. Current:
-
47mA
-
Max. Voltage:
-
DC12V-24V
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
OEM
-
Model Number:
-
EX219
-
Product name:
-
Automatic Door Pedal Switch
-
Technical measure:
-
Active infrared ray of modulation and demodulation
-
Recommend installation height:
-
0.3m height from the ground
-
Reaction time:
-
Relay output <45ms
-
Power supply:
-
AC/DC 12~30V
-
Current:
-
Standby 8.2mA,Operating 47mA
-
Supervisory signal:
-
4.5S MA
-
Signal output:
-
Relay normally open or normally closed
-
Operation temperature:
-
-20℃~55℃
-
Dimension:
-
186x175x53mm
-
Certification:
-
CE
12-24V Automatic Door Pedal Foot Infrared Sensor Switch
What is Foot Sensor Switch?
Foot switch (photoelectric activation sensor) , fixed on the lower part of the wall (embedded), operated by foot without hand’s touch. Usually it is used in circumstances that direct hand touch is not allowed to assure environment clean, such as operating clean rooms in hospital and food manufacturing industries.
Features:
1. With pull in & out socket for easy wiring
2. Adopt microcomputer control with exquisite design of stainless steel wire cover
3. Installation with hidden screw hole, easy to be fixed and stable performance
4. Widely be used in the operating room of hospital and laboratory to prevent hand pollution
5. Detection mode: Receive the open signal by the truncation of infrared ray which operated by foot
6. Active infrared ray of modulation-demodulation controlled by microcomputer
Foot switch (photoelectric activation sensor) , fixed on the lower part of the wall (embedded), operated by foot without hand’s touch. Usually it is used in circumstances that direct hand touch is not allowed to assure environment clean, such as operating clean rooms in hospital and food manufacturing industries.
Features:
1. With pull in & out socket for easy wiring
2. Adopt microcomputer control with exquisite design of stainless steel wire cover
3. Installation with hidden screw hole, easy to be fixed and stable performance
4. Widely be used in the operating room of hospital and laboratory to prevent hand pollution
5. Detection mode: Receive the open signal by the truncation of infrared ray which operated by foot
6. Active infrared ray of modulation-demodulation controlled by microcomputer
Product Descripition
Features
Technical measure: Active infrared ray of modulation and demodulation
Recommend installation height: 0.3m height from the ground
Detection mode: Truncation of infrared ray by foot operated to produce the open signal
Reaction time: Relay output <45ms
Supply power: AC/DC 12~30V
Stand-by current: 8.2mA
Operating current: 47mA
Supervisory signal: 4.5S MA
Signal output: Relay normally open or normally closed
Operation temperature: -20℃~55℃
Interference immunity: Sunlight 81000LUX, incandescent lamp 36000LUX, electronic microwave conforms to 89336CEE standard
Hole Size: 130x120x50mm
Dimension: 186x175x53mm
Detailed Images
Packing & Delivery
Carton Box
Unit Weight: 0.15KG
Standard Package: 100PCS/carton
Carton Weight: 16KG
Carton Size: 51*43*33cm
Delivery Terms: Within 3 Days
Trade Terms: FOB Shenzhen
Our Service
|
Warranty
|
|
One year, long life maintaince
|
|
||
|
Technical Support
|
|
Provide online training and technology support through Mail, Phone, Whatsapp, Skype etc.
|
|
||
|
Inquiry response
|
|
Customers are guaranteed to get the response within Half an hour upon receipt the inquiry.
|
|
||
|
Customized
|
|
OEM can be accepted
|
|
||
