Quick Details
-
Production Capacity:
-
max 420bag/min, min 60bag/min
-
Weight (KG):
-
500
-
Voltage:
-
220V
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Chengyi
-
Model:
-
CY600BF
-
Lanes number:
-
3-10 lanes
-
Capacity:
-
Max.25-40cycle/min/lane
-
Bag size:
-
L:50-180mm W:20-95mm
-
Film width&thickness:
-
Max.600 mm,0.07--0.1mm
-
Measuring Method:
-
1.Volumetric cup;2.weigher
-
Sealing type:
-
back side sealing
-
Cutting type:
-
1. Straight cutting;2.Zigzag cutting 3. Round cutting;4. Die-cut
-
Power supply:
-
1N+PE/50HZ/AC220V/380V/4.1kw
-
Dimension:
-
1685*1300*2005mm
Quick Details
-
Function:
-
FILLING, Wrapping, Sealing, counting
-
Packaging Type:
-
Bags, Foil, Pouch
-
Packaging Material:
-
Plastic, Paper
-
Production Capacity:
-
max 420bag/min, min 60bag/min
-
Weight (KG):
-
500
-
Voltage:
-
220V
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Chengyi
-
Model:
-
CY600BF
-
Lanes number:
-
3-10 lanes
-
Capacity:
-
Max.25-40cycle/min/lane
-
Bag size:
-
L:50-180mm W:20-95mm
-
Film width&thickness:
-
Max.600 mm,0.07--0.1mm
-
Measuring Method:
-
1.Volumetric cup;2.weigher
-
Sealing type:
-
back side sealing
-
Cutting type:
-
1. Straight cutting;2.Zigzag cutting 3. Round cutting;4. Die-cut
-
Power supply:
-
1N+PE/50HZ/AC220V/380V/4.1kw
-
Dimension:
-
1685*1300*2005mm
Pʀᴏᴅᴜᴄᴛ ᴘᴀʀᴀᴍᴇᴛᴇʀs
|
Model
|
CY300BF
|
CY600BF
|
CY900BF
|
||
|
Lanes number
|
2-4 lanes
|
3-10 lanes
|
4-16lane
|
||
|
capacity
|
Max.20-40cycle/min/lane
|
|
|
||
|
Bag size
|
L:50-180mm W:20-70mm
|
L::50-180mm W:20-95mm
|
L::50-180mm W:20-105mm
|
||
|
Film width&thickness
|
Max.300mm.0.07-0.1mm
|
Max.600mm.0.07--0.1mm
|
Max.900mm.0.07--0.1mm
|
||
|
Measuring Method
|
1 long auger；2 short auger； 3 short auger with cup
|
|
|
||
|
sealing type
|
Backsealing/stick bag
|
|
|
||
|
cutting type
|
1 Straight cutting；2 Serrated cutting；3 Round cutting ；4 Abnormal cutting
|
|
|
||
|
Powersupply
|
1N+PE/50HZ/AC220V/380V/3.5kw
|
1N+PE/50HZ/AC220V/380V/5.5kw
|
1N+PE/50HZ/AC220V/380V/7.5kw
|
||
|
Air consumption
|
0.8 MPA 0.8m'/min
|
0.8 MPA0.8m'/min
|
0.8 MPA 0.8m'/min
|
||
|
Dimension
|
1385*918*2005mm
|
1685*1300*2005mm
|
1700*1600*2500mm
|
||
|
weight
|
400kg
|
600kg
|
950kg
|
||
SERVICE & FAQ .
Packaging
:
We will clear every parts, packed firstly with the film, then put in the standard export wooden case ( Fumigation
Free).
Shipping
:
Upon receipt of full payment , delivery date will be in 10-35 days. Shipment cost will depend on the destination, shipment way and the weight of the goods.
After-sale Services:
1. Manuals / Videos of machine installation, adjusting, setting, maintenance are available for you.
2. If any problem happens and you can not find out the solutions, Telecom or Online face to face communication available 24 hours.
3. Engineers & technician are available send to your countries for services if you agree to pay the expenditure.
4. The machine will have one year warranty.
FAQ:
Q1: How to find a packaging machine suitable for my product? Tell us about your product details and packing requirements.
1. Product details (Liquid,Powder,Granule etc.)
2. Bag shape and specification (Length, Width).
3. Packing film material.
4. Net weight of filling product.
Q2: How can I trust you for the first time business ? We aim to establish a long-term cooperative relationship instead of just doing business once. If you don't trust us, then we can use Alibaba trade assurance service, guarantee your money, and guarantee your machine's on-time delivery and machine quality.
Q3: Is engineer available to serve oversea? Yes, but the travel fee is paid by you.In order to save your cost, we will send you a video of full details machine installation and assist you till the end.
Q4. How can we make sure about the machine quality after placing the order? Before delivery, we will send you the pictures and videos for you to check the machine quality.And also you can arrange for quality checking by yourself or by your contacts in China.
Q5: Can you explain me the whole transaction process ? 1. Sign the Contact; 2. Arrange 50% deposit to our factory; 3. Factory arrange production; 4. Testing & detecting the machine before shipping; 5. Inspected by customer or third agency through online or site test;
