Quick Details
-
Graphic Format Supported:
-
AI, BMP, Dst, Dwg, DXF, DXP, LAS, PLT, laser engraving machine
-
Cooling Mode:
-
WATER COOLING
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
XM
-
Dimension(L*W*H):
-
145*96*94 cm
-
Weight (KG):
-
160 KG
-
Core Components:
-
laser source
-
Model:
-
XM-1060/1040
-
Worktable:
-
honeycomb or Aluminum knife
-
Eneraving area:
-
1000*600mm
-
Laser Power:
-
50W/60W/80W/100W/130W/150W
-
Cutting Speed:
-
60mm/s
-
cutting Depth (Acrylic):
-
0-20mm (acrylic)
-
Up and down work table:
-
Upand down adjustable
-
Minimum shaping Character:
-
English 1x1mm (Chinese Characters 2*2mm)
-
Resolution Ratio:
-
0.0254mm(1000dpi)
Quick Details
-
Engraving Area:
-
1000*600mm
-
Laser Type:
-
CO2
-
Engraving Speed:
-
500mm/s Max, 500mm/s Max
-
Graphic Format Supported:
-
AI, BMP, Dst, Dwg, DXF, DXP, LAS, PLT, laser engraving machine
-
Cooling Mode:
-
WATER COOLING
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
XM
-
Dimension(L*W*H):
-
145*96*94 cm
-
Weight (KG):
-
160 KG
-
Core Components:
-
laser source
-
Model:
-
XM-1060/1040
-
Worktable:
-
honeycomb or Aluminum knife
-
Eneraving area:
-
1000*600mm
-
Laser Power:
-
50W/60W/80W/100W/130W/150W
-
Cutting Speed:
-
60mm/s
-
cutting Depth (Acrylic):
-
0-20mm (acrylic)
-
Up and down work table:
-
Upand down adjustable
-
Minimum shaping Character:
-
English 1x1mm (Chinese Characters 2*2mm)
-
Resolution Ratio:
-
0.0254mm(1000dpi)
Products Description
1) Adiustable Speed and Power , Smooth and Precise Engraving and Cutting
2) USB Interface , U-flash Disk Supported , Ethernet cableWIFI ( Optional parts )
3) Air Assist , Remove heat and combustible gases from thecutting surface
4 )Embedded Exhaust Fan . Easier install . Safer transport
5) Rotary Axis , Engrave any cylindrical object ( Optional parts )
6)Aluminum Knife Worktable or Honeycomb Worktable
7)Intuitive Control Panel . Set Speed , power and more controls directly from the laser
8)Water Cooling and Protection System
9) Red light positioning
10)Emergency Stop Button
11 ) Larger Size ,1000'600mm working area
12 ) The lifting platform is electric control
13) Drag-and-chain transmission line .
14 ) Laser focal length : 5CM
Product Acessories
Product Paramenters
|
Model
|
1060 laser engraving cutting machine
|
|
Working area
|
600*1000mm
|
|
Laser type
|
sealed co2 glass laser tube
|
|
Laser power
|
50W/60W/80W/100W/150W
|
|
Engraving speed
|
0-30000mm/min
|
|
Cuttingspeed
|
0-3600mm/min
|
|
Cuttingthickness
|
0-20mm ( depends on materials）
|
|
Resolution rate
|
+0.05mm
|
|
Data tran sfer interface
|
USB2.0
|
|
Working voltage
|
220v+10% 50hz 110生10%60hz
|
|
Min shaping character
|
Character:2*2mm letter:1*1mm
|
|
Software
|
Rdworksv8' CorelDraw/AutoCAD
|
|
Supported graphic formats
|
BMP PCX TGA TIF PLT CDR
|
|
Working temperature
|
0-45°C
|
|
Working humidity
|
5%-90%
|
|
Rsolution ratio
|
<4500DPI
|
|
Optional parts
|
Rotary axis,water chiller 3000/5000/5200
|
|
Package
|
Packing in exportwooden cases
|
applicable materials:
Acrylic,leather,wood, rubber, double-color board,MDF.plwwoodbamboo, paper, cardboard, marble, granite, stone, glass, fabric,textile, coated metal, painted metal, anodised aluminum etc.
Details Images
LASER TUBE
Closed Co2 laser tube, long life, stable powerInstallation of reinforcement settings, the lasertube is not easy to collide and cause damage when movingthe machine.
(EFR,RECI,CDWG,YONGLI,JOY.Optional)
INDUSTRIAL LASER HEAD
High precision retractable laser head
easy to adjust focal length, equipped
with red light positioning system,
accurate positioning, reduce materialloss.
Auto-blowing to protect laser head
and prevent the laser burning.
USA II-VI LENS
Imported USA II-VI Lens, suitable for vanous
environments,and has high precision and high
speed.
FAMOUS BRAND BELT
The ONK brand belt, wear resistance,
good stability, compact structure and low noise
LEADING CHAIN
The current lead and breather
pipe are included in it.
Thicker,more stable
Keep the laser head from shaking
REFLECTOR
45°mirror adjustment set.Easy to adjust laser path
1.Adopt advanced laser engraving and cutting control system: Ruida RDC6442control system, the control pannal support different language include ChineseEnglish, French, Pyccko, Portuguese, Turkish, German, Spanish, Vietnamese,Korean, Italian.
2.Standard RDWorksV8 software: it support 15 different languages, include:Chinese Enalish.lapanese. Erench.German.Portuauese. Polish.SpanishRussian, Korean, Vietnamese,Indonesian, Italian, Turkrish,Arabic.t can compatible with many other software, like Coreldraw, PhotoshopAutoCAD,TAlIMA,etc.You can use these software to make designs, then import to Rdworks tccut or engrave.
3. RDworks software support files in different format: Al,DXF,PLTDST,BMPDSB,EPS,DAT,NC,RDBGIF,PG,IPEG,PE,JFIF,PNG,MNG,ICO,CUR,TIF,TIFF,TGAPCX,WBMP,WMF,EMF,JBG,2C,JPCPGXRAS,PNM,PGM,PPMSKA,RAW
4.Storage: The main board has EMS Memory which enables the user to storemore than 100 files
5. Laser output control: Can regulate the laser power from 1-100% accordingto different material.
6. Interface: USB2.0 interface support connect to computer by USB cable, italso support offline work.
LINEAR GUIDE
XY axis apply imported square railsEnsures stable operation, highprecision and long life.
PLATFORM LIFTING
lt allows you to process materials ofvarious sizes,can be lifted in Z direction(up-and-down) to get more workingspace.
AMPEREMETER
The ammeter can detect whether the lasertube current is normal.(Optional)
THERMOMETER
Real-time display of the temperature of the lasertube, prolonging the service life of the laser tube
SUPPORTED SOFTWARE
CorelDRAW,AutoCAD,LightBurnsupported
BUILT-IN EXHAUST FAN
Built-in Exhaust Fan, Easier install.Safer transport
