Quick Details
-
Brand Name:
-
E.P
-
Dimension(L*W*H):
-
3x2.5x2.1 m
-
Name:
-
Coal Briquette Machine
-
raw material:
-
lignite, coal slime, charcoal, carbon black
-
roller diameter:
-
650mm
-
production:
-
10-12 t/h
-
Power:
-
45kw
-
briquettes shape:
-
round pillow square etc
-
briquettes size:
-
15-80mm diameter
-
Application:
-
Dry Powder Briquette Machine
-
brand:
-
E.P
-
Weight:
-
7.5T
Quick Details
-
Weight (KG):
-
7200
-
Production Capacity:
-
10-12t/h
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
E.P
-
Dimension(L*W*H):
-
3x2.5x2.1 m
-
Name:
-
Coal Briquette Machine
-
raw material:
-
lignite, coal slime, charcoal, carbon black
-
roller diameter:
-
650mm
-
production:
-
10-12 t/h
-
Power:
-
45kw
-
briquettes shape:
-
round pillow square etc
-
briquettes size:
-
15-80mm diameter
-
Application:
-
Dry Powder Briquette Machine
-
brand:
-
E.P
-
Weight:
-
7.5T
Products Description
The hydraulic pressure briquette machine is equipped with hydraulic system which can provide with high and stable pressure, which is suitable for raw materials like coal, coke, DRI powder, mineral powder, etc.
|
Model
|
Capacity
|
Power
|
Max. pressure
|
Weight
|
Dimension
|
|
HSYQ-430
|
1-3(ton/h)
|
37kw
|
120T
|
10T
|
3.7*2.8*2.2(m)
|
|
HSYQ-520
|
2-5(ton/h)
|
55kw
|
400T
|
12T
|
3.7*2.8*2.2(m)
|
|
HSYQ-560
|
4-8(ton/h)
|
55kw
|
400T
|
16T
|
3.7*2.8*2.2(m)
|
|
HSYQ-700
|
6-10(ton/h)
|
75kw
|
400T
|
18T
|
4*2.8*2.5(m)
|
|
HSYQ-738
|
8(ton/h)
|
90kw
|
400T
|
20T
|
4.2*3.2*2.8(m)
|
|
HSYQ-750
|
6-11(ton/h)
|
90kw
|
400T
|
22T
|
4.5*4*2.8(m)
|
|
HSYQ-850
|
8-15(ton/h)
|
110kw
|
400T
|
25T
|
4.5*4*2.8(m)
|
Features
The surfaces of the rollers are made of special manganese steel alloy, so the rollers are durable and can be used for a long time. Besides, the range of the diameter of the rollers is wide.
The pressure of the roller briquette machine is adjustable. The briquetting effect of the briquette making machine is excellent, and the finished briquettes are of high hardness.
The speed reducer adopts hardened gear that can improve the performance and the service life of the speed reducer.
The briquette production line is highly automatic. Thus, it is labor-saving and high-output.
Production Line
Certifications
Why choose us
Our Advantages
1. We have a wealth of project experience and can provide complete technical guidance.
2. Provide integrated installation and complete guidance services
Strong Technical Team
Customized service:
customize equipment according to your requirements.
Installation service: send our workers to your country to install the production line.
Installation service: send our workers to your country to install the production line.
Packaging & Shipping
Packaging Specification:
Outside Package : Wooden Packing as Exported Standard.
Inner Package : Stretch Film
About Shipping
We can be responsible for the shipping according to the customers's requirments to ship the machines by sea, express or air. Besides, we can cooperate with your agent if you have shipping forwarder in China.
FAQ
1. How high is the pressure of the roller briquette machine?
It is customizable. Generally, it’s up to the raw material and the hardness of the finished briquettes.
2. How long is the service life of the moulds?
65Mn(for 10-12 months)；9Cr2Mo（for 1.5-2 years）；stainless steel（for 3-4 years）
3. What about the output?
It depends on the size of the finished briquettes and the density of the material.
Formula: Output/hour=Volume of a single briquettes*density of raw material*amount of the briquettes/hour*rotating speed*60 mins
4. Daily maintenance
Every half a year, change the -220# oil in the speed reducer;
Every month, grease the bearing once and add some -46# anti-wear hydraulic oil into the hydraulic pump.
