Quick Details
-
Warranty:
-
25 years
-
Brand Name:
-
Blueusn
-
Model Number:
-
BSM565M10-72HPH
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
2278*1134*35mm
-
Max Power(Pmax) [W]:
-
565W
-
Open Circuit Voltage (Voc) [V]:
-
50V
-
Cell Type:
-
Monocrystalline
-
Weight:
-
28.6kg
-
Maximum Module Efficiency:
-
21.68%
-
Short Circuit Current (Isc) [A]:
-
14.14A
-
Junction Box:
-
3 bypass diode
-
Operating Temperature:
-
-40℃ to + 85℃
-
Module Dimensions:
-
2278*1134*35mm
-
Certificate:
-
CE/INMETRO/TUV
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Half Cell
-
Panel Efficiency:
-
21.87%
-
Warranty:
-
25 years
-
Brand Name:
-
Blueusn
-
Model Number:
-
BSM565M10-72HPH
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
2278*1134*35mm
-
Max Power(Pmax) [W]:
-
565W
-
Open Circuit Voltage (Voc) [V]:
-
50V
-
Cell Type:
-
Monocrystalline
-
Weight:
-
28.6kg
-
Maximum Module Efficiency:
-
21.68%
-
Short Circuit Current (Isc) [A]:
-
14.14A
-
Junction Box:
-
3 bypass diode
-
Operating Temperature:
-
-40℃ to + 85℃
-
Module Dimensions:
-
2278*1134*35mm
-
Certificate:
-
CE/INMETRO/TUV
Product Description
|
SPECIFICATIONS
|
|
|
|
|
|
|||||
|
Module Type
|
BSM545M10-72HPH
|
BSM550M10-72HPH
|
BSM555M10-72HPH
|
BSM560M10-72HPH
|
BSM565M10-72HPH
|
|||||
|
Maximum Power (Pmax/W)
|
545
|
550
|
555
|
560
|
565
|
|||||
|
Operating Voltage(Vmp/V)
|
42.06
|
42.16
|
42.24
|
42.33
|
42.42
|
|||||
|
Operating Current(Imp/A)
|
12.96
|
13.05
|
13.14
|
13.23
|
13.32
|
|||||
|
Open-Circuit Voltage(Voc/V)
|
49.7
|
49.8
|
49.9
|
50
|
50.1
|
|||||
|
Short-Circuit Current(Isc/A)
|
13.84
|
13.94
|
14.04
|
14.14
|
14.24
|
|||||
|
Module Efficiency（%）
|
21.1
|
21.3
|
21.49
|
21.68
|
21.87
|
|||||
|
STC: Irradiance 1000W/m2, Cell Temperature 25°C Air Mass AM1.5
|
|
|
|
|
|
|||||
|
|
|
|
|
|
||||||
Full Certificates
Production Process
Packing
Packing Configuration:
36pcs/carton, 720pcs/40hq
