Quick Details
-
Brand Name:
-
DGM
-
Fork Length:
-
1220mm
-
Fork Width:
-
125mm
-
Overall Dimensions:
-
3800*1230*2095mm
-
Weight (KG):
-
3000 kg
-
After-sales Service Provided:
-
Overseas service center available
-
Type:
-
Sit-Down Counterbalance Forklift Trucks (IC)
-
Engine:
-
Japanese engine ISUZU /Nissan
-
Loading Capacity:
-
3 tonne / 6000 lbs
-
lift height:
-
2-stage 3.3m/3.5m/4m mast; 3-stage4.5m/5m/5.5m/6m/7.3m mast
-
Tire:
-
Pneumatic tires (solid/air)
-
Options:
-
full enclosed Cab with heater/ air conditioning
-
Attachments:
-
Side-shifter/Rotator/Push / Pull /Paper Roll clamps / fork positioner
-
Mast:
-
Duplex mast or Triplex mast
-
Related products:
-
3.5 ton /5 ton/7 ton/10 ton forklift
Quick Details
-
Min. Lifting Height:
-
125mm
-
Warranty:
-
1 Year
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
DGM
-
Fork Length:
-
1220mm
-
Fork Width:
-
125mm
-
Overall Dimensions:
-
3800*1230*2095mm
-
Weight (KG):
-
3000 kg
-
After-sales Service Provided:
-
Overseas service center available
-
Type:
-
Sit-Down Counterbalance Forklift Trucks (IC)
-
Engine:
-
Japanese engine ISUZU /Nissan
-
Loading Capacity:
-
3 tonne / 6000 lbs
-
lift height:
-
2-stage 3.3m/3.5m/4m mast; 3-stage4.5m/5m/5.5m/6m/7.3m mast
-
Tire:
-
Pneumatic tires (solid/air)
-
Options:
-
full enclosed Cab with heater/ air conditioning
-
Attachments:
-
Side-shifter/Rotator/Push / Pull /Paper Roll clamps / fork positioner
-
Mast:
-
Duplex mast or Triplex mast
-
Related products:
-
3.5 ton /5 ton/7 ton/10 ton forklift
Product Description
Specification
|
MODEL
|
|
CPCD30
|
|
|
Load capacity
|
|
3000 kg
|
|
|
Load center
|
|
500 mm
|
|
|
Power type
|
|
Diesel
|
|
|
Max. lifting speeds(with load)
|
|
400mm/s
|
|
|
Max. driving speeds(with/without load)
|
|
18/20km/h
|
|
|
Max towering (with load)
|
|
15.5/10.5kn
|
|
|
Grade ability (with load)
|
|
15/20 %
|
|
|
Lifting height (H1)
|
|
3000mm
|
|
|
Free lift
|
|
80 mm
|
|
|
Tilting angles(forward α-backward β)
|
|
6°/12°
|
|
|
Min. turning radius
|
|
2500mm
|
|
|
Min. Right angle aisle width
|
|
2110mm
|
|
|
Min. under-clearance
|
|
135mm
|
|
|
|
Overall length(including fork) (A)
|
3800 mm
|
|
|
|
Overall width (B)
|
1230mm
|
|
|
|
Overall height(mast lowered) (H)
|
2110 mm
|
|
|
|
Overall height(mast extended) (H2 )
|
4270mm
|
|
|
Overall height to overhead guard (H3)
|
|
2110mm
|
|
|
Fork overhang (A1)
|
|
465mm
|
|
|
Wheel base(A2)
|
|
1700 mm
|
|
|
Tread
|
Front tread(B1)
|
1000 mm
|
|
|
|
Rear tread (B2)
|
970mm
|
|
|
Tire
|
Front tire
|
28×9-15
|
|
|
|
Rear tire
|
6.50-10
|
|
|
Total weight
|
|
4320kg
|
|
|
Fork width(B3)
|
|
125 mm
|
|
|
Fork thickness(H4)
|
|
45 mm
|
|
|
Backrest height
|
|
1225 mm
|
|
|
Fork length (A3)
|
|
1220mm
|
|
|
|
Engine model
|
490
|
|
|
|
Rated power
|
39 kw
|
|
|
|
Rotate speed at rated power
|
2650rpm
|
|
|
|
Max. Torque
|
157 nm
|
|
|
|
Rotate speed at max. Torque
|
1980 rpm
|
|
|
Type of power shift
|
|
Tor-con
|
|
|
Packing details
|
2PCS/20’CNT; 6PCS/40’CNT
|
|
|
