Zhangjiagang Sky Machine Co.,Itd is located at Leyu Economic Development Zone of Zhangjiagang City.Our Company was founding
in 2008.We committed to do the World’s most competitive liquid drink packaging manufacture suppliers.Focus on providing customers with safe,energy,saving,efficient equipment.And high quality,fast and personalized service. We sincerely invite businesses aroundthe world to build a professional relationship with us based on trust,benefits and the promising possibility for future development.
- Product Details
- {{item.text}}
Quick Details
-
Bottle Volume(ml):
-
500 ml
-
Place of Origin:
-
China
-
Brand Name:
-
SKYM
-
Year:
-
2020
-
Voltage:
-
380V 50HZ 3Phase
-
Dimension(L*W*H):
-
1600*600*1610mm
-
Hollow part volume:
-
20
-
Clamping Force (kN):
-
100
-
Power (kW):
-
17.5
-
Weight (KG):
-
250 KG
-
Bottle volume range:
-
50-2000ml
-
Speed:
-
1200-1600bph
-
bottle type1:
-
Water Bottle,Oil Bottle,Cosmetic Bottle
-
bottle type2:
-
detergent Bottle
-
bottle type3:
-
Beverage Bottle,Pet Can,Transparent Bottle
-
bottle type4:
-
Plastic Bottle,Drink Bottle,Empty Bottle
-
Product name:
-
Injection Blow Molding Machine
-
Type:
-
Stretch Pet Blow Moulding
-
Bottle material:
-
Pet Plastic
-
Function:
-
Pet Blower Bottles Making Machine
Quick Details
-
Neck Diameter(mm):
-
28 mm
-
Max.Bottle Diameter(mm):
-
180 mm
-
Max.Bottle Height(mm):
-
360 mm
-
Bottle Volume(ml):
-
500 ml
-
Place of Origin:
-
China
-
Brand Name:
-
SKYM
-
Year:
-
2020
-
Voltage:
-
380V 50HZ 3Phase
-
Dimension(L*W*H):
-
1600*600*1610mm
-
Hollow part volume:
-
20
-
Clamping Force (kN):
-
100
-
Power (kW):
-
17.5
-
Weight (KG):
-
250 KG
-
Bottle volume range:
-
50-2000ml
-
Speed:
-
1200-1600bph
-
bottle type1:
-
Water Bottle,Oil Bottle,Cosmetic Bottle
-
bottle type2:
-
detergent Bottle
-
bottle type3:
-
Beverage Bottle,Pet Can,Transparent Bottle
-
bottle type4:
-
Plastic Bottle,Drink Bottle,Empty Bottle
-
Product name:
-
Injection Blow Molding Machine
-
Type:
-
Stretch Pet Blow Moulding
-
Bottle material:
-
Pet Plastic
-
Function:
-
Pet Blower Bottles Making Machine
Low cost High Effeciency Semi Automatic PET Bottle Blow Molding Machine
Semi-Automatic Pet Bottle Blowing Machine Plastic Bottle Blow Molding Machineis suitable for producing PET plastic containers and bottles. It is widely used to produce the carbonated bottle, mineral water,carbonated drink bottle, pesticide bottle oil bottle cosmetics,wide-mouth bottle etc. Adopting double crank to adjust mould, heavy locking mould, stable and fast, Adopt infrared oven to heat the perform, the perform rotated and heated equally.The air system has been divided into two parts: pneumatic action part and bottle blow part to meet the different requirements for the action and blow. It can provide sufficient and steady high pressure for blowing large irregular shaped bottles.The machine is also equipped with muffler and oiling system to lubricate the mechanical part of the machine.The machine can be operated in the step-by-step mode and the semi-auto mode.The machine is small with low investment, easy and safe to operate.
Related Models Of Machines
SKY-8Y 0.01L-2L
SKY-B 5L-10L
SKY-B 3L-12L
SKY-12 10L-25L
SKY-SA4 5ML-1.5L
SKY-SA4 5ML-1.5L
Product Paramenters
|
Model
|
SKY-8Y
|
SKY-12
|
SKY-SA4
|
SKY-5L
|
SKY-10L
|
|
Bottle Volume
|
0.01~2 Liter
|
10L-25L
|
0.01L-2.5L
|
0.01L-5L
|
5L-10L
|
|
Production Speed (pcs/h(500ml))
|
1200~1600
|
90-180
|
2000
|
300-800
|
300-500
|
|
Blower(L*W*H)
|
160*60*161
|
218*77*196
|
190*88*180
|
187*63*145
|
187*63*145
|
|
Blower/Weight
|
500kg
|
1000kg
|
1000kg
|
600kg
|
800kg
|
|
Power
|
17.5kw
|
40kw
|
18kw
|
17.5kw
|
17.5kw
|
|
Heater(L*W*H)
|
187*63*1450cm
|
237*68*135cm
|
190*66*160cm
|
187*63*145cm
|
187*63*145cm
|
|
Weight
|
250
|
380
|
380
|
250
|
250
|
Real Picture Of Customer Factory
Auxiliary Equipment
High pressure air compressor
Air Type Water Chiller
Bottle Mold
