Quick Details
-
Structure:
-
Screw conveyor
-
Place of Origin:
-
Henan, China
-
Voltage:
-
220/380/410/460/480 V
-
Marketing Type:
-
New Product 2023
-
Weight (KG):
-
100 kg
-
Product name:
-
Screw Conveyor
-
Color:
-
Customized Color
-
Capacity:
-
0~70 T/h
-
Pipe diameter:
-
89-273 mm/Customised
-
Pipe length:
-
1-12m
-
Inclination Angle:
-
0~60°
-
Hopper Volume:
-
200L/Customised
-
Customised:
-
Support
Quick Details
-
Power:
-
2.2 KW, 0.4KW-22KW
-
Warranty:
-
1 Year
-
Width or Diameter:
-
Customization
-
Structure:
-
Screw conveyor
-
Place of Origin:
-
Henan, China
-
Voltage:
-
220/380/410/460/480 V
-
Marketing Type:
-
New Product 2023
-
Weight (KG):
-
100 kg
-
Product name:
-
Screw Conveyor
-
Color:
-
Customized Color
-
Capacity:
-
0~70 T/h
-
Pipe diameter:
-
89-273 mm/Customised
-
Pipe length:
-
1-12m
-
Inclination Angle:
-
0~60°
-
Hopper Volume:
-
200L/Customised
-
Customised:
-
Support
Product Paramenters
|
Model
|
Diameter
|
Screw Rotation Speed
|
Inclination Angle
|
Conveyor Length
|
|
|
(mm)
|
(r/min)
|
(degree)
|
(m)
|
|
XD-89
|
89
|
20-290
|
<60
|
0-12
|
|
XD-108
|
108
|
|
|
|
|
XD-133
|
133
|
|
|
|
|
XD-159
|
159
|
|
|
|
|
XD-219
|
219
|
|
|
|
|
XD-273
|
273
|
|
|
|
Product introduction
Product Advantages
Product Display
Our Advantages
After Sales Service Terms:
1: If technical support is required, the solution should be provided within 1 hour during working hours. During non working hours, respond within 12 hours and provide me with a solution.
2: For parts that need to be repaired or replaced: During the warranty period, our company will bear all the costs, while outside the warranty period, we will charge a basic fee.
3: Our company has inventory of all conventional accessories used, and generally ships them within two days after confirming the problem
4: The technical support used for our equipment is free for life. You can directly contact your sales manager or add
Whatsapp +8618603739862 or WeChat 8618603739862
FAQ
Q：What data do I need to provide if l want to customize a screwconveyor?
Answer: The distance to be conveyed, the name of the material, and the conveyingvolume.
Q：What other screw conveyors can be customized?
Answer: material, increase silo, increase pulley, increase silo wall vibrator, etc
Q：What should be paid attention to during use?
Answer: 1. Fill lubricating oil regularly
2. Do not overload the delivery volume
3. Please stop and check in time if there is abnormal noise
Q：Which materials are not suitable for screw conveyors?
Answer: 1.Materials larger than 3 mm are not suitable for screw conveyors
2.The material is not allowed to be broken during the conveying process, suchas: tablets,etc.
3. Materials or liquid materials with particularly good fluidity
