Quick Details
-
Type:
-
Thermal paste, Thermal grease
-
Certification:
-
RoHS Reach HF Approval ISO9001
-
Color:
-
White
-
Tensile Strength:
-
7.0KV/mm
-
Thermal Conductivity:
-
2.0w/mk
-
Working temperature:
-
-40~150℃
-
Density:
-
3.2g/cm3
-
Capacity:
-
5ml
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Dingtai
-
Model Number:
-
DTH2526-2W-5ML
-
Type:
-
Thermal paste, Thermal grease
-
Certification:
-
RoHS Reach HF Approval ISO9001
-
Color:
-
White
-
Tensile Strength:
-
7.0KV/mm
-
Thermal Conductivity:
-
2.0w/mk
-
Working temperature:
-
-40~150℃
-
Density:
-
3.2g/cm3
-
Capacity:
-
5ml
Product Parameters
|
Test Item
|
Units
|
Product Model
|
Test Standard
|
|
|
|
DTH2526-2W-5ML
|
|
|
Color
|
/
|
White
|
Visual
|
|
Thermal Resistance
|
Cin2/W@40psi
|
0.02
|
ASTM D5470
|
|
Thermal conductivity
|
(W/M.K)
|
2.0
|
ISO22007-2:2008
|
|
Specific gravity
|
g/cm²
|
3.2
|
ASTM D792
|
|
Volume resistivity
|
Ω.cm
|
≥1.0*10¹³
|
ASTM D257
|
|
Compressive strength
|
KV/mm
|
≥7.0
|
ASTM D149
|
|
Viscosity
|
Pa.s
|
200
|
ASTM D2196
|
|
Volatile Content
|
%
|
0.3
|
HG/T2502-11993 5201
|
|
Temperature
|
℃
|
40-150
|
Dingtai TM
|
Products Description
Product Feature
1.New environmental protection products, no corrosion to the substrate.
2.Good thermal conductivity and liquidity,long operation time,the overall curing fast.
3.good electrical performance, good chemical stability and weather resistance; Has a good insulation waterproof, moistureproof and shockproof characteristics; suitable for automatic glue filling equipment.
4.good heat and cold resistance.
Application
(1). Power supply sealing of high-power LED bulb lamp.
(2). Sensor, transformer, signal amplifier, high voltage resistor package and potting protection;
(3). Encapsulation of HID headlight ballast in the automotive industry, encapsulation protection of module power supply of automobile ignition system, etc.
(4). Sealing and protection of general electronic components, power modules and printed circuit boards, waterproof and moisture-proof, high voltage resistance.
