Quick Details
-
Brand Name:
-
FY-SOLAR
-
Model Number:
-
FY-40M
-
Place of Origin:
-
Zhejiang, China
-
Panel Dimensions:
-
668x455x 28mm
-
Solar Cell:
-
A Grade
-
Color:
-
Blue or Black
-
Cable Connector:
-
no
-
Frame:
-
Anodized,Aluminum Alloy
-
Front Glass:
-
Low Iron,High Transmisson,Tempered Glass
-
Output Cable:
-
no
-
Certificate:
-
TUV;CE;ISO, TUV;CE;ISO
-
Junction Box:
-
no
-
OEM Order:
-
yes
Quick Details
-
Type:
-
PERC
-
Panel Efficiency:
-
15%
-
Warranty:
-
25 years
-
Brand Name:
-
FY-SOLAR
-
Model Number:
-
FY-40M
-
Place of Origin:
-
Zhejiang, China
-
Panel Dimensions:
-
668x455x 28mm
-
Solar Cell:
-
A Grade
-
Color:
-
Blue or Black
-
Cable Connector:
-
no
-
Frame:
-
Anodized,Aluminum Alloy
-
Front Glass:
-
Low Iron,High Transmisson,Tempered Glass
-
Output Cable:
-
no
-
Certificate:
-
TUV;CE;ISO, TUV;CE;ISO
-
Junction Box:
-
no
-
OEM Order:
-
yes
| Model | FY-30M | FY-35M | FY-40M | FY-45M | FY-50M |
| Maximum Power(Pmax) | 30w | 35w | 40w | 45w | 50w |
| Cell type | monocrystalline | ||||
| Dimensions(mm) | 710 x360x28 | 545 x515x 28 | 668x455x 28 | 665x545x 28 | 668 x545x 28 |
| Maximum Power Current (lmp) |
1.69A |
1.93A | 2.3A | 2.48A | 2.78A |
| Maximum Power Voltage (Vmp) | 17.75V | 17.178V | 17.6V | 18.1V | 18V |
| Short Circuit Current (lsc) | 1.9A | 1.97A | 2.58A | 2.58A | 3.2A |
| Open Circuit Voltage (Voc) | 21.97V | 22V | 22.03V | 23V | 22V |
| Power Tolerance | 0~+3% | ||||
| Weight | 3.1Kg | 3.4Kgs | 3.7kgs | 4.3Kgs | 4.3Kgs |
| Temperature Coefficient of Voc | -0.38%/℃ | ||||
| Temperature Coefficient of Isc | 0.04%/℃ | ||||
| Temperature Coefficient of Pmax | -0.47%/℃ | ||||
| Nomial Operating cell Temperature(NOCT) | 4 7℃± 2℃ | ||||
|
