Customized rope hoist Electrical Travelling Single girder Overhead Bridge Electric Crane 5 ton 10 ton 20 ton

Customized rope hoist Electrical Travelling Single girder Overhead Bridge Electric Crane 5 ton 10 ton 20 ton

FOB Reference Price: Get Latest Price

≥1 Sets

US $7422

≥5 Sets

US $5560

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Max. Lifting Height:: 9m

Place of Origin:: Jiangsu

Brand Name:: Macaw

Max. Lifting Load:: 5 T (Customized Acceptable)

Max. Liftiing Height:: 12m (Customized Acceptable)

Span:: 10.5m (Customized Acceptable)

Lifting Speed:: 5/0.8 m/min

Hoisting motor:: 6.1:1 kw

Power Supply:: 380V 50Hz 3 Phase

Control Method:: Pendant Control

Work Duty:: A5

Packing:: Export Standard

Color:: Yellow

Quick Details

Weight (KG):: 4500

Application:: Building Material Shops, Machinery Repair Shops,

Rated Loading Capacity:: 5 ton

Max. Lifting Height:: 9m

Place of Origin:: Jiangsu

Brand Name:: Macaw

Max. Lifting Load:: 5 T (Customized Acceptable)

Max. Liftiing Height:: 12m (Customized Acceptable)

Span:: 10.5m (Customized Acceptable)

Lifting Speed:: 5/0.8 m/min

Hoisting motor:: 6.1:1 kw

Power Supply:: 380V 50Hz 3 Phase

Control Method:: Pendant Control

Work Duty:: A5

Packing:: Export Standard

Color:: Yellow

Products Description

European Standard 5 ton Electric Single Girder Overhead Crane

* Advanced design, collection the advantages of industry's top brands.

Safe & reliable, precise positioning, and efficient operations. * Wideley used in varios application. * High efficiency and make the most use of space. * Core components imported, frequency control system as standard. * Non-standard products can be designed.

Recommend Products

SG Wire Rope Hoist DG Wire Rope Hoist SG Overhead Crane DG Overhead Crane

FAQ

Q. What's the information should I provide when inquiry on Electric crane and electric hoist?

More parameters, more better.

Lift capacity ?
span ?
lift height ?
power sourceor other specials you give us will be more appreciated ?

Plesee provide us the rquest lifting capacity, lifting height, span, power supply, building dimesnsion etc.

And if you can give us your design drawing, that will be very helpful.

Q.Which kind crane can you provide?
With products of single girder & double girder overhead cranes, gantry cranes, general overhead cranes, Eurosystem light cranes, jib cranes, explosion-proof cranes and etc, We are able to provide you with complete competitive solutions for material handling based on your demands.

Q. Can this type work in hazardous environment?
Sure! We can customize for you, acid proof or explosion proof, no problem for that.

Q. Can you provide the serious lifting tools?
Sure, we can provide any lift tools such as lift sling belt, lift clamp, grab, magnet or other specials as your requirement!

Q. How can we install the crane?
Our senior engineer can be your side to do the installation guide service and training. Moreover, our best sales can visit
yourcountry.

Q:The space of my workshop is limited, can the crane ok for mine?
Thanks for your question. For low headroom workshop, we have the Special products. The detail dimension please consult our professional engineer.

Q. Do you provide spare parts?
Yes, of course, we can provide motors, reducers, brakes, drums,wire ropes and any other spare parts in connection with the cranes and hoists.

Technical Paremeter

Please contact me for customized parameters

Basic Data
Crane Span (m)	7.5	10.5	13.5	16.5	19.5	22.5	25.5	28.5
Crane Weight (t)	1.56	2.01	2.82	3.69	4.77	5.77	6.81	8.9
Trolley Weight (t)	0.36	0.36	0.36	0.36	0.36	0.36	0.36	0.36
Max.Wheel Load (KN)	27.5	32.4	32.4	34.7	37.4	39.8	42.4	47.7
Min.Wheel Load (KN)	5.2	6.9	6.9	8.8	11.3	13.8	16.2	21.1
Crane Wheel Quantity (pcs)	4	4	4	4	4	4	4	4
Recommend Crane Rail	P22	P22	P22	P22	P22	P22	P22	P22
Operation Speed (m/min)
Lifting Speed	5:0.8	5:0.8	5:0.8	5:0.8	5:0.8	5:0.8	5:0.8	5:0.8
Trolley Speed	5~20	5~20	5~20	5~20	5~20	5~20	5~20	5~20
Bridge Speed	8~32	8~32	8~32	8~32	8~32	8~32	8~32	8~32
Driven Motor Power (KW)
Lifting Motor	6.1/1	6.1/1	6.1/1	6.1/1	6.1/1	6.1/1	6.1/1	6.1/1
Trolley Motor	0.64	0.64	0.64	0.64	0.64	0.64	0.64	0.64
Bridge Motor	0.44*2	0.64*2	0.64*2	0.64*2	0.64*2	0.64*2	0.96*2	0.96*2
Crane Power	7.62	8.02	8.02	8.02	8.02	8.02	8.66	8.66
Main Dimension (mm)
Top of rail height (mm) b	9000 (or specified by clients)
Top Clearance (mm) h	≥200 （GB/T 14405-2011）
Hook to crane Top (mm) c	904	984	994	1108	1236	1419	1539	1586
Rail to crane Top (mm) a	600	600	750	750	850	950	950	1000
Lifting height (mm) h	8552	8502	8645	8557	8353	8281	8603	8340
Ceiling to floor height (mm) c	9800	9800	9950	9950	10050	10150	10150	10200
Girder Bottom Height (mm) f	8950	8900	9043	8953	8814	8742	8999	8848
Hook Approach L.(mm) h1	450	450	540	540	690	690	690	710
Hook Approach R.(mm) h2	410	410	490	490	540	540	540	560
Rail Center to left wall (mm) dL	206	206	208	230	232	232	232	246
Rail Center to right wall (mm) dR	206	206	208	230	232	232	232	246
Bridge Wheel Base (mm) W	1800	1800	1800	2200	2700	3100	3800	4500
Trolley Rail Guage (mm) Lx	/	/	/	/	/	/	/	/
Buffer Height (mm) H2	100	100	100	100	150	150	150	150
Crane Width (mm) B	2096	2096	2156	2556	3150	3550	4290	5010
Guiding (contact) Force (KN) S	9.5	10.5	11.5	12.5	13.5	14.9	15	15.1
Buffer Force (KN) Bf	11	15	19	23	27	32	36	40

Note:

Cranes have many kinds of specifications to choose,the data in this table base on 9M top of rail. This is for user and designing institue reference only when selecting cranes type. More detailed data and technical solution,please contact with us.

Details Images

Packaging & Delivery

Electric overhead crane girder part
