Quick Details
-
Inner size (L*W*H):
-
5750mm*2800mm*2540mm
-
Structural connection:
-
M12><35 high strength carriage bolt
-
Surface treatment:
-
Electrostatic spraying plastic powder baking paint
-
Roofing:
-
Roof tile: 980 color steel veneer, thickness 0.42mm
-
Suspended ceiling:
-
831 color steel ceiling plate, 0.3mm
-
Structural plate:
-
MGO high-strength floor, thickness 18mm
-
Interior corner:
-
Corner 40400.5mm color steel folding piece
-
Waterproof performance:
-
The arched roof is divided into two sides and drains by gravity.
-
Size:
-
20ft 0r 40ft
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
GUIZU
-
External dimensions (L*W*h):
-
5950mm*3000mm *2800mm
-
Inner size (L*W*H):
-
5750mm*2800mm*2540mm
-
Structural connection:
-
M12><35 high strength carriage bolt
-
Surface treatment:
-
Electrostatic spraying plastic powder baking paint
-
Roofing:
-
Roof tile: 980 color steel veneer, thickness 0.42mm
-
Suspended ceiling:
-
831 color steel ceiling plate, 0.3mm
-
Structural plate:
-
MGO high-strength floor, thickness 18mm
-
Interior corner:
-
Corner 40400.5mm color steel folding piece
-
Waterproof performance:
-
The arched roof is divided into two sides and drains by gravity.
-
Size:
-
20ft 0r 40ft
Products Description
|
Dimensions
|
6m (L) * 3m (W) * 2.75 m(H), accept custom
|
|
|
|
|
Frame
|
corner column, channel steel
|
|
|
|
|
Wall panel/Top plate
|
exterior wall panel 0.5mm galvanized large corrugated iron plate, interlayer 50mm glass wool, interior wall 0.36mm galvanized
sheet |
|
|
|
|
Floor
|
glass magnesium board
|
|
|
|
|
Door
|
stainless steel
|
|
|
|
|
Window
|
aluminum alloy
|
|
|
|
|
Circuit
|
laid
|
|
|
|
|
Please contact us if you want to know more information about our products
|
|
|
|
|
Product Paramenters
|
item
|
EPS
|
Glass Wool
|
TPS Board
|
Rock Wool
|
|
waterproof
|
★★★★★
|
★★★
|
★★★★★
|
★★★
|
|
fireproof
|
★★
|
★★★★★
|
★★★★★
|
★★★★★
|
|
Heat Insulation
|
★★★
|
★★★★
|
★★★★
|
★★★★
|
|
Sound Insulation
|
★★★★
|
★★★★
|
★★★★★
|
★★★★
|
|
Price Comparison
|
★★
|
★★★
|
★★
|
★★★★
|
|
Density Range
|
10-14kg/m3
|
100-120kg/m3
|
40-200kg/m3
|
100-250kg/m3
|
|
Accessories Name
|
Description
|
|
Ground Beam
|
14#/16# H-beam, 12# channel steel;
100*100*3.0 /150*75*3.0 / 120*60*3.0galvanized steel tube; 120*120*3.0 / 150*150*3.0 bending parts |
|
Pillar/Column
|
100*100*3.0 /150*75*3.0 / 120*60*3.0galvanized steel tube;
120*120*3.0 / 150*150*3.0 bending parts |
|
Floor beam
|
100*100*3.0 / 150*75*3.0 / 120*60*3.0 / 60*60*2.0 galvanized steel tube;
60*60*3.0 / 120*120*3.0 / 150*150*3.0 bending parts |
|
Floor Purlin
|
8# channel steel;
80*80*2.0 / 50*100*2.0 / 40*80*2.0 galvanized steel tube |
|
Stairs
|
150*30 C-type steel
|
|
Walkway Board
|
anticorrisive woods
|
|
External Wall
|
0.8mm/1.5mm/2.0mm Corrugated galvanized steel board;
0.46mm pre-painted galvanized steel board |
|
Internal Wall
|
0.46mm / 0.36mm / 0.26mm pre-painted galvanized steel board
|
|
Roof Panel
|
0.8mm/1.5mm/2.0mm Corrugated galvanized steel board;
0.46mm pre-painted galvanized steel board |
|
Edge
|
PVC capping seal, bamboo and woods fiber capping seal
|
|
Floor
|
Glass magnesium board, PVC composition tile, ceramic tiles
|
|
Window
|
Sliding window, casement window, hanging window, double-glazed glass window（thickness can be customized)
|
|
Door
|
Security door, plastic steel door, steel door, stainless steel door
|
