Quick Details
-
Brand Name:
-
ETCR
-
Model Number:
-
ETCR5000
-
Accuracy Class:
-
High
-
Output Voltage:
-
9.6V
-
Operating Temperature:
-
-10°C~40°C
-
Dimensions:
-
240mm*170mm*68 mm
-
Voltage Test:
-
Wire voltage: 1.0V ~ 2000V; phase voltage: 1.0V ~ 1000V
Quick Details
-
Phase:
-
Three Phase
-
Measuring Energy Range:
-
9999.9MWh
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
ETCR
-
Model Number:
-
ETCR5000
-
Accuracy Class:
-
High
-
Output Voltage:
-
9.6V
-
Operating Temperature:
-
-10°C~40°C
-
Dimensions:
-
240mm*170mm*68 mm
-
Voltage Test:
-
Wire voltage: 1.0V ~ 2000V; phase voltage: 1.0V ~ 1000V
Product Description
Power consumption: Current consumption 490mA, battery work 8 hours continuously
Current clamp type: ETCR 040B current clamp: 35mm * 40MM(4PCS), CT size: Ф40mm . Current clamp type: ETCR 008B current clamp:
7.5mm * 13mm(4PCS), CT size: Ф8mm .Current clamp type: ETCR 068B current clamp: 68mm * 68mm(4PCS), CT size: Ф68mm
Channel number: 4U/4I
Linevoltage:1.0V～2000V
Phase voltage: 1.0V～1000V
Frequency: 40Hz～70Hz
Power parameter: W，VA，var，PF，DPF，cosφ，tanφ
Electrical parameters: Wh，varh，Vah
Harmonic: Yes, 0 to 50 times
Total harmonic distortion:Yes, 0 to 50 times, each phase
Expert mode: Yes
Transient record group: 150 groups
Voltage flicker: Yes
Start current mode: Yes, 100 seconds
Three phase unbalance: Yes
Record: 300 days (record 20 parameters at the same time, record every 5 seconds, 1 points) Alarm:40 different types of parameters,
the 12800 group alarm log
Phasor diagram display: automatic
Screenshot capacity: 60
Menu language: Chinese and English
Communication interface: USB
Automatic shutdown: The instrument does not shut down automatically when the alarm / trend chart recording / transient capture
mode is in progress；In other test mode, 15 minutes without key operation, prompt automatic shutdown after 1 minutes.
Test line: Voltage test line 3m, Current clamp 2m
Operating temperature and humidity: -10℃～40℃;below 80%Rh
Storage temperature and humidity: -10℃～60℃;below 70%Rh
Input impedance:Test voltage input impedance: 1MΩ
Accessory:
Host: 1; instrument box: 1; test line: 5 (yellow, green, red, blue, black, 1); Alligator clip: 5; Pen: 5; charger: 1;
CD: 1; lithium battery group: 1; 2G memory card: 1; current sensor :12.
CD: 1; lithium battery group: 1; 2G memory card: 1; current sensor :12.
