Quick Details
-
Product name:
-
smart access control reader
-
Material:
-
ABS
-
Size:
-
86mm*86mm*10mm
-
Working voltage:
-
DC 12V±10%
-
Sensing distance:
-
8-15mm
-
Weight:
-
100g
-
Working current:
-
100mA
-
Card reader type:
-
EM card
-
Feature:
-
Water-proof
-
MOQ:
-
1000pcs
Quick Details
-
Frequency:
-
13.56Mhz
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
hecere
-
Product name:
-
smart access control reader
-
Material:
-
ABS
-
Size:
-
86mm*86mm*10mm
-
Working voltage:
-
DC 12V±10%
-
Sensing distance:
-
8-15mm
-
Weight:
-
100g
-
Working current:
-
100mA
-
Card reader type:
-
EM card
-
Feature:
-
Water-proof
-
MOQ:
-
1000pcs
Product Description
|
Product name
|
Smart access control reader
|
|
Size
|
86mm×86mm×10mm
|
|
Weight
|
100g
|
|
Working voltage
|
DC 12V±10%
|
|
Sensing distance
|
8-15mm
|
|
Communication distance
|
100m
|
|
Working current
|
100mA
|
|
Working temperature
|
-30℃—85℃
|
|
Relative humidity
|
20%—80%
|
|
Card reader type
|
EM card or Mifare one card
|
|
Card reading distance
|
EM: 5-15M, MF1: 3-8CM
|
Product introduction
Instructions for use:
When the ID card is close to the Wiegand ID card reader, the red light turns green and flashes once and then turns red, and the buzzer sounds once to indicate sending data. For the same ID card, the interval between two card readings is shorter than 500mS, and no send data. After reading the card, if the ID card is still in the RF card area, the card reader will not give any prompts and will not send data. Different ID cards enter the RF card area respectively, and the reader will read the card continuously and output data.
