- Product Details
- {{item.text}}
Quick Details
-
Type:
-
Pedestal Sinks
-
Place of Origin:
-
Gujarat, India
-
Brand Name:
-
Vistaar
-
Model Number:
-
105
-
Color:
-
Red
-
Product Name:
-
Hand Wash Basin
-
Usage:
-
Washing Hands
-
Shape:
-
Round Ceramic Washbasin
-
Feature:
-
Easy Clean
-
Style:
-
Modern Desgin
-
Size:
-
Custom Size
-
Packing:
-
Carton Box
-
Finish:
-
Glossy
Quick Details
-
Project Solution Capability:
-
graphic design, 3D model design, total solution for projects
-
Application:
-
Bathroom
-
Design Style:
-
Asian
-
Type:
-
Pedestal Sinks
-
Place of Origin:
-
Gujarat, India
-
Brand Name:
-
Vistaar
-
Model Number:
-
105
-
Color:
-
Red
-
Product Name:
-
Hand Wash Basin
-
Usage:
-
Washing Hands
-
Shape:
-
Round Ceramic Washbasin
-
Feature:
-
Easy Clean
-
Style:
-
Modern Desgin
-
Size:
-
Custom Size
-
Packing:
-
Carton Box
-
Finish:
-
Glossy
Products Description
Product Gallery / Factory Display
Technical Specification
|
Name of Test
|
As Per IS 2556 (Part) 1994
|
Vistaar Overseas Value
|
||
|
Water Absorption
|
Average value should not exceed more than 0.5 %
|
Max 0.30 % show better vitrification.
|
||
|
Crazing Test
|
No crazing up to 2 cycle up 5 hrs each cycle or 10 hrs at pressure 0.34 to 0.37 Mps.
|
No problem up to 4 cycle and no crazing.
|
||
|
Chemical Resistance
|
No loss of reflectivity of the glaze when compared with control sample.
|
No loss of reflectivity of the glaze when compared with control sample.
|
||
|
Modules of Repture
|
Not less than 60 Mpa.
|
Minimum 65 Mpa. / Minimum 80 Mpa.
|
||
|
Resistance to Staining and Burning
|
No stain shall remain on either of test piece.
|
No stain shall remain on either of test piece.
|
||
|
Discoloration
|
None on all visible surface.
|
None on all visible surface.
|
||
|
Wavy Finish
|
None on all visible surface.
|
None on all visible surface.
|
||
|
Note : All products dimension may vary 10 % to 15 % from the dimension given in the catalogue.
|
|
|
||
Trouble Shooting Guide
|
PRODUCT
|
PROBLEM
|
PROBABLE REASONS
|
CORRECTIVE ACTIONS
|
||
|
One Piece Water Closet
|
Water not coming in Bowl area while flushing.
|
Mechanism inside tank may not be working properly.
|
Change the center pump of mechanism.
|
||
|
|
Water is continuously leaking Inside the Bowl.
|
There is no water in tank.
|
Increase the ball cock height to the maximum level.
|
||
|
|
Water Quantity insufficient for effective Flushing.
|
Mechanism inside tank may not be working properly.
|
Change the center pump of mechanism.
|
||
|
|
Uneven flow of water from both side of Closet.
|
Ball Cock height adjusted at lower level.
|
Increase the ball cock height to the maximum level.
|
||
|
|
Overflow chocked and foul bad odour.
|
Waste coupling used may be full threaded.
|
Waste coupling should be replaced by slot cut coupling.
|
||
|
|
Water deposit on tap platform area and inside.
|
Basin is not flued in level or bracket is not in level.
|
Should be done by proper leveling.
|
||
|
|
There is no tap hole in Basin.
|
Tap hole can be semi punched from back side.
|
Tap Hole should be created by plumber from semi punched area.
|
||
|
|
|
|
Insert the flush pipe up to the end of inlet for Pan / Closet check whether flush pipe is not covering flush hole which is in both side of inlet.
|
||
|
|
|
Closet / Pan may not be Levelled.
|
Should be done by proper levelling.
|
||
|
AFTER SALES SERVICE :
|
|
AFTER RECEIVING THE PRODUCTS, IF YOU FOUND ANY QUALITY PROBLEM, PLEASE CONTACT US IN TIME BY EMAIL. WE WILL DEFINETLY FIND A MOST SUITABLE SOLUTIONS FOR IT.
|
|
||
