Quick Details
-
Model Number:
-
PH-11106
-
Specification:
-
Optional
-
Length:
-
5.9 meter/length or 11.9 meter/length
-
Thickness:
-
Optional
-
Standard:
-
ISO/WRAS/ROSH
-
Diameter:
-
DN20-DN2300
-
Pressure:
-
SDR7.4-SDR33
-
Certificate:
-
CE/WRAS/ISO/ROSH
-
Color:
-
Black or customized
-
Application:
-
Water supply/gas distribution/Mining/Irrigate
-
Surface:
-
Smooth surface
-
Life span:
-
75-100 years
-
Connection method:
-
Butt fusion/socket fusion/electrofusion
Quick Details
-
Processing Service:
-
Moulding, Cutting
-
Place of Origin:
-
Guangxi, China
-
Brand Name:
-
SZ
-
Model Number:
-
PH-11106
-
Specification:
-
Optional
-
Length:
-
5.9 meter/length or 11.9 meter/length
-
Thickness:
-
Optional
-
Standard:
-
ISO/WRAS/ROSH
-
Diameter:
-
DN20-DN2300
-
Pressure:
-
SDR7.4-SDR33
-
Certificate:
-
CE/WRAS/ISO/ROSH
-
Color:
-
Black or customized
-
Application:
-
Water supply/gas distribution/Mining/Irrigate
-
Surface:
-
Smooth surface
-
Life span:
-
75-100 years
-
Connection method:
-
Butt fusion/socket fusion/electrofusion
Our Advantages
HDPE pipe parameter sheet
|
ISO 4427 Pipe Series
|
|
S 3.2
|
S 4
|
S 5
|
S 6,3
|
S 8
|
S 10
|
S 12,5
|
S 16
|
|
|
ASTM F714 DR
|
|
DR 7.4
|
DR 9
|
DR 11
|
DR 13.6
|
DR 17
|
DR 21
|
DR 26
|
DR 33
|
|
|
Nominal Pressure PE 100
|
|
PN = 25 bar
|
PN = 20 bar
|
PN = 16 bar
|
PN = 12,5 bar
|
PN = 10 bar
|
PN =
8 bar
|
PN =
6 bar
|
PN =
5 bar
|
|
|
Nominal Size DN (mm)
|
Equiv Size (inch)
|
Wall
(mm)
|
Wall
(mm)
|
Wall
(mm)
|
Wall
(mm)
|
Wall
(mm)
|
Wall (mm)
|
Wall (mm)
|
Wall (mm)
|
|
|
20
|
1/2"
|
3.0
|
2.3
|
2.0
|
1.8
|
1.200
|
1.000
|
0.600
|
0.610
|
|
|
25
|
3/4"
|
3.5
|
3.0
|
2.3
|
2.0
|
1.500
|
1.200
|
0.800
|
0.760
|
|
|
32
|
1
|
4.4
|
3.6
|
3.0
|
2.4
|
2.000
|
1.500
|
1.000
|
0.970
|
|
|
40
|
1 1/4
|
5.5
|
4.5
|
3.7
|
3.0
|
2.400
|
2.000
|
1.200
|
1.210
|
|
|
50
|
1 1/2
|
6.9
|
5.6
|
4.6
|
3.7
|
3.000
|
2.400
|
2.000
|
1.520
|
|
|
63
|
2
|
8.6
|
7.1
|
5.8
|
4.7
|
3.800
|
3.000
|
2.500
|
1.910
|
|
|
75
|
2 1/2
|
10.3
|
8.4
|
6.8
|
5.6
|
4.500
|
3.600
|
2.900
|
2.270
|
|
|
90
|
3
|
12.3
|
10.1
|
8.2
|
6.7
|
5.400
|
4.300
|
3.500
|
2.730
|
|
|
110
|
4
|
15.1
|
12.3
|
10.0
|
8.1
|
6.600
|
5.300
|
4.200
|
3.330
|
|
|
125
|
5
|
17.1
|
14.0
|
11.4
|
9.2
|
7.400
|
6.000
|
4.800
|
3.790
|
|
|
140
|
5 1/2"
|
19.2
|
15.7
|
12.7
|
10.3
|
8.300
|
6.700
|
5.400
|
4.240
|
|
|
160
|
6
|
21.9
|
17.9
|
14.6
|
11.8
|
9.500
|
7.700
|
6.200
|
4.850
|
|
|
180
|
6
|
24.6
|
20.1
|
16.4
|
13.3
|
10.700
|
8.600
|
6.900
|
5.450
|
|
|
200
|
8
|
27.4
|
22.4
|
18.2
|
14.7
|
11.900
|
9.600
|
7.700
|
6.060
|
|
|
225
|
8
|
30.8
|
25.2
|
20.5
|
16.6
|
13.400
|
10.800
|
8.600
|
6.820
|
|
|
250
|
10
|
34.2
|
27.9
|
22.7
|
18.4
|
14.800
|
11.900
|
9.600
|
7.580
|
|
|
280
|
10
|
38.3
|
31.3
|
25.4
|
20.6
|
16.600
|
13.400
|
10.700
|
8.480
|
|
|
315
|
12
|
43.1
|
35.2
|
28.6
|
23.2
|
18.700
|
15.000
|
12.100
|
9.700
|
|
|
355
|
14
|
48.5
|
39.7
|
32.2
|
26.1
|
21.100
|
16.900
|
13.600
|
10.900
|
|
|
400
|
16
|
54.7
|
44.7
|
36.3
|
29.4
|
23.700
|
19.100
|
15.300
|
12.300
|
|
|
450
|
18
|
61.5
|
50.3
|
40.9
|
33.1
|
26.700
|
21.500
|
17.200
|
13.800
|
|
|
500
|
20
|
67.6
|
55.8
|
45.4
|
36.8
|
29.700
|
23.900
|
19.100
|
15.300
|
|
|
560
|
22
|
75.7
|
62.5
|
50.8
|
41.2
|
33.200
|
26.700
|
21.400
|
17.200
|
|
|
630
|
24
|
85.1
|
70.3
|
57.2
|
46.3
|
37.400
|
30.000
|
24.100
|
19.300
|
|
|
710
|
28
|
95.9
|
79.3
|
64.5
|
52.2
|
42.100
|
33.900
|
27.200
|
21.800
|
|
|
800
|
32
|
|
89.3
|
72.6
|
58.8
|
47.400
|
38.100
|
30.600
|
24.500
|
|
|
900
|
36
|
|
|
81.7
|
66.1
|
53.300
|
42.900
|
34.400
|
27.600
|
|
|
1000
|
40
|
|
|
90.2
|
73.5
|
59.300
|
47.700
|
38.200
|
30.600
|
|
|
1200
|
48
|
|
|
109.09
|
88.2
|
71.100
|
57.200
|
45.900
|
36.700
|
|
|
1400
|
54
|
|
|
127.28
|
102.9
|
83.000
|
66.700
|
53.500
|
42.900
|
|
|
1600
|
64
|
|
|
|
117.5
|
94.800
|
76.200
|
61.200
|
49.000
|
|
