- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
Worider
-
Model Number:
-
QX-Solar Panle- 300
-
Place of Origin:
-
Guangdong, China
-
Panel Dimensions:
-
1640*992*30mm/other
-
Light intensity:
-
800W/m²
-
Battery temperature:
-
20°C
-
Air quality =:
-
1.5
-
Wind Speed:
-
1m/s
Quick Details
-
Cell size:
-
182*30.3/other
-
Type:
-
PERC, Half Cell, Bifacial, Double-glass, All Black, MWT, IBC, HJT, hbc, N-TYPE, TOPCON, BIPV, Flexible, Overlapping
-
Warranty:
-
25 years
-
Brand Name:
-
Worider
-
Model Number:
-
QX-Solar Panle- 300
-
Place of Origin:
-
Guangdong, China
-
Panel Dimensions:
-
1640*992*30mm/other
-
Light intensity:
-
800W/m²
-
Battery temperature:
-
20°C
-
Air quality =:
-
1.5
-
Wind Speed:
-
1m/s
Products Description
|
Model Type
|
Power(W)
|
Vmp(V)
|
Imp(A)
|
Voc(V)
|
Isc(A)
|
|
WD-300
|
300
|
31.4
|
9.56
|
39
|
9.86
|
|
Weight
|
18kg
|
|
|
Cell
|
60 cells poly solar cell
|
|
|
Junction Box
|
Protection class IP67/IP68,with bypass diodes
|
|
|
Cable
|
4mm² Solar cable, 90cm length
|
|
|
Connector
|
Compatible
|
|
|
Temperature rating
|
|
|
|
Rated battery operating temperature
|
45±2℃
|
|
|
Maximum power temperature coefficient
|
-0.4%/℃
|
|
|
Open circuit voltage temperature coefficient
|
-0.29%/℃
|
|
|
Short circuit current temperature coefficient
|
-0.05%/℃
|
|
|
Limit parameter
|
|
|
|
Operating temperature
|
-40-+85℃
|
|
|
Maximum system voltage
|
1000/1500VDC
|
|
|
Maximum fuse rated current
|
15A
|
|
