Quick Details
-
Application:
-
fabric cutting
-
Place of Origin:
-
Hubei, China
-
Brand Name:
-
TIMING
-
Power:
-
30kw
-
Dimension(L*W*H):
-
5850*2890*824mm
-
Weight:
-
3500 KG
-
Cutting speed:
-
0-50000mm/min; 0-60000mm/min
-
Cutting thickness (after vac-sorb):
-
Max 70mm and 75mm (according to the cloth)
-
Cutting style:
-
up-down
-
Cutting accuracy:
-
≤±1mm
-
Air pressure ,flow:
-
0.55Mpa 160L/min
-
Software:
-
Automatic cutting system Copyright
-
Power supplier:
-
AC380V/50HZ
-
absorption working way:
-
uniform absorption
-
Air Pump:
-
motor and fun togethe
-
servo motor brand:
-
Panasonic
Quick Details
-
Production Capacity:
-
30sets/month
-
Voltage:
-
380v
-
Marketing Type:
-
Hot Product 2021
-
Application:
-
fabric cutting
-
Place of Origin:
-
Hubei, China
-
Brand Name:
-
TIMING
-
Power:
-
30kw
-
Dimension(L*W*H):
-
5850*2890*824mm
-
Weight:
-
3500 KG
-
Cutting speed:
-
0-50000mm/min; 0-60000mm/min
-
Cutting thickness (after vac-sorb):
-
Max 70mm and 75mm (according to the cloth)
-
Cutting style:
-
up-down
-
Cutting accuracy:
-
≤±1mm
-
Air pressure ,flow:
-
0.55Mpa 160L/min
-
Software:
-
Automatic cutting system Copyright
-
Power supplier:
-
AC380V/50HZ
-
absorption working way:
-
uniform absorption
-
Air Pump:
-
motor and fun togethe
-
servo motor brand:
-
Panasonic
Product Application
Cutter markets suitable for widely industly ,for instance : leisure fashional suits,children's garments,suits,knitting casual/
leisure suits,underware,swimsuit,corsage,seat cushion,massage chair,yacht/houseboat seat,shoes,cat,cold protective
clothing,golf bag,handbag,home textiles,cow-bag,sleeping bag,tent, apparel,automotive, and furniture and soft fabric as
well as other industries.
|
Type
|
TMCC-1725/M
|
TMCC-2025/M
|
TMCC-2225/M
|
|
Cutting area
|
1700*2500
|
2000*2500
|
2500*2500
|
|
Weight
|
2100KG
|
2200KG
|
2400KG
|
|
Size(length,width,height)
|
5760*2610*1500
|
5760*2910*1500
|
5760*3100*1500
|
|
Cutting speed:
|
0-50000mm/min
|
Cutting style:
|
straight knife up-down
|
|
Cutting accuracy:
|
≤±1mm
|
Cutting thickness:
(after vacuum suction) |
max50/70/90mm
(according to the cloth) |
|
Deceleration system
|
Planetary Gear
|
Max speed of blade working
|
4000rpm/min
|
|
Power supplier:
|
AC380V/50HZ
|
Softerware:
|
automatic cutting system copyright
|
|
SPECIFICATIONS FOR MOTORS
|
|
|
|
|||
|
MOTORS |
X AXIS
|
1000
|
Watt
|
|||
|
|
Y AXIS
|
750
|
Watt
|
|||
|
|
Z AXIS
|
400
|
Watt
|
|||
|
MOTORS |
T AXIS
|
200
|
Watt
|
|||
|
|
Conveyor
|
750
|
Watt
|
|||
|
|
Pick up
|
400
|
Watt
|
|||
|
Vacuum |
Power
|
18.5
|
Watt
|
|||
|
|
frequency
|
7
|
Level
|
|||
|
|
Average consumption
|
12KW - 18KW
|
KW
|
|||
MEN SUIT MATERIAL
FASHION WARE MATERIAL
CAR CUSHION MATERIAL
Main Features
1) Computer design, automatic typesetting, save original materials.
2) Computer controlled and automatic cutting, save the human resource, mass production.
3)Support many kinds of formats, direct open general dress design format, typesetting software.
4)High cutting accuracy, self-design of automatic sharpen cutter, high quality of cutter makes life longer.
5) No need print out, save the typesetting, with high repeated utilization, plate marking management is convenient.
5)Easy to change the spare part, and lower cost;
6)Nice automation, easy to operate.
Machine Parts
Name: Vacuum Drive
Original: JAPAN OR TAIWAN
Machine Parts
Name: Vacuum motor
Original: TAIWAN
Machine Parts
Name: cables
Original: Germany
Machine parts
Name: Inverter
Original: JAPAN OR TAIWAN
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
|
Packaging
|
|
|
|
Size
|
20' FR
|
|
|
Weight
|
2.4 T
|
|
|
Packaging Details
|
The standard package is plywood packages
Plywood #1: Dimension:3380*2950*1800mm (Length*Width*Height) Gross weight:1600KG Plywood #2: Dimension:2800*2600*1300mm(Length*Width*Height) Gross weight:800KG We will use tarpaulin to protect the packing for waterproof purpose. |
|
