Quick Details
-
Panel Size:
-
10*1000
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
Energy Saving
-
Pixel Pitch:
-
15.625 31.25, 31.25
-
Usage:
-
OUTDOOR
-
Tube Chip Color:
-
FULL COLOR
-
Display Function:
-
Video
-
Certificate:
-
CE RoHS Certifications
-
LED chip:
-
Cree + Nichia + Epistar + Opto + Silan
-
Warranty:
-
2years
-
Power Supply:
-
Meanwell
-
Module size:
-
500mm x 1000mm
-
Life span:
-
100000hours
Quick Details
-
Application:
-
Outdoor, building media decoration
-
Brand Name:
-
Sunrise
-
Color:
-
Full color
-
Panel Size:
-
10*1000
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
Energy Saving
-
Pixel Pitch:
-
15.625 31.25, 31.25
-
Usage:
-
OUTDOOR
-
Tube Chip Color:
-
FULL COLOR
-
Display Function:
-
Video
-
Certificate:
-
CE RoHS Certifications
-
LED chip:
-
Cree + Nichia + Epistar + Opto + Silan
-
Warranty:
-
2years
-
Power Supply:
-
Meanwell
-
Module size:
-
500mm x 1000mm
-
Life span:
-
100000hours
Advertising Led Transparent Mesh Screen P10 outdoor Curtain Mesh Display
Sunrise mesh display technical spec:
|
Model |
HMX-15 |
HMX-20 |
HMX-30 |
|
Pixel Pitch(H/V)
|
15.625mm/15.625mm |
31.25mm/15.625mm |
31.25mm/31.25mm |
|
Pixels (RGB) |
DIP346 |
DIP346 |
DIP346 |
|
Brightness(CD/ m2) |
>8500nits |
>6500nits |
>5500nits |
|
Transparency rate(%) |
50% |
70% |
70% |
|
Display size |
500x1000mm |
500x1000mm |
500x1000mm |
|
Viewing Angle (H/V) |
110/60 |
110/60 |
110/60 |
|
Best view distance |
8-160 |
8-160 |
15-300 |
|
Resolution(Dots/ m2) |
4096 |
2048 |
1024 |
|
Max. Power (w/ m2) |
400 |
400 |
400 |
|
Average Power (w/ m2)
|
160 |
160 |
160 |
|
Ingress Protection |
IP68 (Back/front) |
IP68 (Back/front) |
IP68 (Back/front) |
|
Refresh rate |
2380 |
2380 |
2380 |
|
Weight (kgs/ m2)
|
16 |
13 |
13 |
|
Thickness (cm) |
1.3-5.8 |
1.3-5.8 |
1.3-5.8 |
|
Thickness of installation
|
11.8cm |
11.8cm |
11.8cm |
Sunrise Mesh series unique features:
1. Extremely light weight----------14kgs/sqm, can be install onto building glass wall.
2. Fast installation ---------Average 5-10 seconds to install an individual cabinet.
3. Stability long life time-------Low consumption of electricity to increase the lifetime of LEDs.
4. Energy efficient--------average 160W per sqm
5. Simple structure-------Reduce the cost of steel structure (Average 5 USD per sqm)
6. Labor efficient--------Reduce the labor time and cost by 60%
Sunrise mesh transparent media facade bar type led display
Power energy saving comparison:
Special module design: 500mm x 1000mm, support vertical installation, has stronger
forward-looking design for building installation, front maintainance, easy for maintaiance of the led screen.
1. No Escape Tool design : screen environment mostly glass building in case of fire, escape and rescue are very urgent and important, Sunrise P15.625 outdoor screen tool-free disassembly function screen rear side of two seconds, especially respect for life and fully meet fire safety requirements.
2. unique within the industry, ultra-light weight : unit box weighs only 7.45KG (50 * 100CM), the project is only 1500KGS screen body weight thus reducing the building to support the weight of the body on the screen, minimize security risks!!
3.Standardized installation framework (standard frame size 200CM wide X100CM height), small on-site construction difficulty, high precision, fast efficiency! The measure, the industry faster than 3-5 times, greatly reducing the body of the screen frame and fixed installation time, substantial savings in installation costs.
4. The screen is fixed to the body frame fixed firmware process is simple, easy to operate, completely within the industry complex and time-consuming step shortcomings.
5. The dual power backup design: display body control card power supply and separate power supply, reducing power interference between the two, improve quality screen body stability.
6. Ultra power-saving design: each squared average power consumption control at about 150W, than peers of similar products saving more than 50% each year for the owner saving about eight million (100 square color screen, runs daily from 8:00 am to 22:00, ie 14 hours calculated)
Super light weight Sunrise mesh display are widely used in building media facade and decoration video display.
Sunrise transparent mesh display for building media facade
Overview effect:
Sunrise mesh display: Looking from the outdoor
Sunrise mesh display: Looking from the indoor to outdoor
Sunrise transparent led display: aging testing in factory
