Quick Details
-
The discharge rate:
-
780A(5S)
-
Battery Size:
-
12V 100AH
-
Brand Name:
-
Greensun
-
Model Number:
-
JFM100-12
-
Place of Origin:
-
Jiangsu, China
-
Weight:
-
28KG
-
Electric Energy:
-
1200 Wh
-
Product name:
-
solar deep cycle battery
-
OEM Order:
-
Acceptable
-
Separator:
-
absorbent glass mat (GEL)
-
Material:
-
High Pure Lead
-
Container Material:
-
ABS
-
Certification:
-
CE ISO RoHS MSDS
Quick Details
-
Chargeable:
-
Yes
-
Battery Type:
-
Deep Cycle: Sealed Gel
-
Cycle Life:
-
4000 cycles
-
The discharge rate:
-
780A(5S)
-
Battery Size:
-
12V 100AH
-
Brand Name:
-
Greensun
-
Model Number:
-
JFM100-12
-
Place of Origin:
-
Jiangsu, China
-
Weight:
-
28KG
-
Electric Energy:
-
1200 Wh
-
Product name:
-
solar deep cycle battery
-
OEM Order:
-
Acceptable
-
Separator:
-
absorbent glass mat (GEL)
-
Material:
-
High Pure Lead
-
Container Material:
-
ABS
-
Certification:
-
CE ISO RoHS MSDS
Product Description
Key Features:
♦Safety seal, Deflating system ,Simple maintenance, long lasting,Stable quality and high reliability
♦Gelled electrolyte made by mixing sulfuric acid with silica fume.
♦The electrolyte is gel like, immobile and does not leak, enabling
uniform reaction of each part of the plate.
♦High rate discharge performance due to tight assembly technology
♦Strong heat dissipation and wide operating temperature range
♦Avoid acid mist being separated out, environment friendliness
♦Efficient venting system release excessive gas automatically
♦Gelled electrolyte made by mixing sulfuric acid with silica fume.
♦The electrolyte is gel like, immobile and does not leak, enabling
uniform reaction of each part of the plate.
♦High rate discharge performance due to tight assembly technology
♦Strong heat dissipation and wide operating temperature range
♦Avoid acid mist being separated out, environment friendliness
♦Efficient venting system release excessive gas automatically
Specification
|
Battery Model
|
JFM100-12
|
JFM150-12
|
JFM200-12
|
JFM250-12
|
JFM300-12
|
||||
|
Nominal Voltage
|
12 Volt
|
|
|
|
|
||||
|
Nominal Capacity
(10HR)
|
100 AH
|
150AH
|
200AH
|
250AH
|
300AH
|
||||
|
Dimensions
L*W*H
|
330*173*212
|
484*170*241
|
522*240*219
|
520*269*220
|
520*269*220
|
||||
|
Max. Discharge Current
|
1000A (5s)
|
1500A (5s)
|
1800A (5s)
|
2500A (5s)
|
2500A (5s)
|
||||
|
Terminal (Optional)
|
T11
|
T11
|
T11
|
T11
|
T11
|
||||
|
Operating Temp.Range
|
Discharge : -15 ~ 50℃ (5~122°F)
Charge : 0 ~ 40℃ (32-104°F)
Storage : -15 ~ 40℃ (5~104°F)
|
|
|
|
|
||||
|
Nominal Operating Temp.Range
|
25 ± 3℃ (77±5°F)
|
|
|
|
|
||||
|
Internal Resistance
|
Approx 5.9mΩ
|
Approx 3.5mΩ
|
Approx 3.24mΩ
|
Approx 2.5mΩ
|
Approx 2.5mΩ
|
||||
|
Cycle Use
|
14.5V~14.9V at 25 ℃(77 ºF)Temp. Coefficient -30mV/ C
|
10-15 Years
|
|
|
|
||||
|
Standby Use
|
13.6V~13.8V at 25 ℃(77 ºF)Temp. Coefficient -20mV/ C
|
3-5 Years
|
|
|
|
||||
|
Container Material
|
ABS
|
|
|
|
|
||||
