Quick Details
-
WIFI:
-
NO
-
Network:
-
NO
-
Customized support:
-
Yes
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
ELSINE
-
Model Number:
-
EWP21, WP22, WP23 WP24
-
Material:
-
PC+stainless Steel
-
Standard(s):
-
BS 1363 Part 2
-
Rating:
-
13 Amp 250V~
-
Switch type:
-
Double pole
-
Contact Gap:
-
3mm minimum
-
IP rating:
-
IP56 with plug in use
-
Covered by RoHS directive:
-
No
-
Covered by WEEE directive:
-
No
-
Warranty:
-
3months-1year
-
Certification:
-
CE
Quick Details
-
Rated Voltage:
-
250V
-
Rated Current:
-
13A
-
Application:
-
Residential / General-Purpose
-
WIFI:
-
NO
-
Network:
-
NO
-
Customized support:
-
Yes
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
ELSINE
-
Model Number:
-
EWP21, WP22, WP23 WP24
-
Material:
-
PC+stainless Steel
-
Standard(s):
-
BS 1363 Part 2
-
Rating:
-
13 Amp 250V~
-
Switch type:
-
Double pole
-
Contact Gap:
-
3mm minimum
-
IP rating:
-
IP56 with plug in use
-
Covered by RoHS directive:
-
No
-
Covered by WEEE directive:
-
No
-
Warranty:
-
3months-1year
-
Certification:
-
CE
Notice
:
all prices here for reference only, we would adjust our products' prices according to the lastest Exchange rate & Material prices accordingly!
We are glad to offer samples for testing,but customers have to pay sample & freight cost themselves, we would return you sample cost when we get your standard order.
|
Technical Specifications ( WP21, WP22 products)
|
|
|
|
|
||||
|
Standard(s)
|
BS 1363 Part 2
|
|
|
|
||||
|
Rating
|
13 Amp 250V~
|
|
|
|
||||
|
Switch type
|
Double pole
|
|
|
|
||||
|
Contact Gap
|
3mm minimum
|
|
|
|
||||
|
Terminal Capacity
|
3 x 2.5mm2 3 x 4mm2 2 x 6.0mm2
|
|
|
|
||||
|
IP rating
|
IP56 with plug in use
|
|
|
|
||||
|
Covered by RoHS directive
|
No
|
|
|
|
||||
|
Covered by WEEE directive
|
No
|
|
|
|
||||
|
WP21
|
|
|
|
|
||||
|
Size
|
111mm x 154mm x 80mm
|
|
|
|
||||
|
Number of cable entries
|
5 x 20mm. 1 in each of 3 sides and 2 in the remaining side
1 drill out entry 20/25mm in rear face
|
|
|
|
||||
|
WP22
|
|
|
|
|
||||
|
Size
|
171mm x 154mm x 80mm
|
|
|
|
||||
|
Number of cable entries
|
8 x 20mm. 1 in each of the 2 sides and 3 in each of the top and bottom faces
1 drill out entry 20/25mm in rear face
|
|
|
|
||||
