1. Hydraulic forging
2. Manual feeding type
3. Diameter and length of pipe can be customized
- Product Details
- {{item.text}}
Quick Details
-
Machine code:
-
ZGJ-114
-
Suitable max. pipe length:
-
4000mm
-
Suitable pipe wall thickness:
-
0.8-4.5mm
-
Suitable pipe outer diameter:
-
20-114mm
-
Production speed:
-
Around 30 seconds per forging
-
Die numbers:
-
One
-
Die material:
-
SKD12
-
Main motor power:
-
11kW
-
Power:
-
11kW
-
After-sales Service Provided:
-
Video technical support
Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
Zhenhuan
-
Weight (KG):
-
4500
-
Machine code:
-
ZGJ-114
-
Suitable max. pipe length:
-
4000mm
-
Suitable pipe wall thickness:
-
0.8-4.5mm
-
Suitable pipe outer diameter:
-
20-114mm
-
Production speed:
-
Around 30 seconds per forging
-
Die numbers:
-
One
-
Die material:
-
SKD12
-
Main motor power:
-
11kW
-
Power:
-
11kW
-
After-sales Service Provided:
-
Video technical support
MACHINE DESCRIPTION
This tube swaging machine is used tomake
round stainless steel tubes, steel pipes, copper pipes, aluminum pipes, into various kind of decorative pipes and tapered pipes.
MAIN FEATURES
MACHINE SPECIFICATION
|
No.
|
Item
|
Data
|
|
1
|
Machine code
|
ZGJ-114
|
|
2
|
Suitable max. pipe length
|
4000mm
|
|
3
|
Suitable pipe wall thickness
|
0.8-4.5mm
|
|
4
|
Suitable pipe outer diameter
|
20-114mm
|
|
5
|
Production speed
|
Around 30 seconds per forging
|
|
6
|
Die numbers
|
One
|
|
7
|
Die material
|
SKD12
|
|
8
|
Main motor power
|
11kW
|
|
9
|
Machine size
|
5000 x 1200 x 1400mm (L x W x H)
|
|
10
|
Machine weight
|
About 4500kg
|
