Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
JINCHEN
-
Product Name:
-
JCA SERIES
-
Structure:
-
Catridge
-
Size:
-
Customzised
-
Material:
-
Carbon Stee
-
Filter Type:
-
5 Micron Stainless Pleated Filter
Quick Details
-
Type:
-
Filter Drier
-
Application:
-
Refrigeration Parts
-
Weight (KG):
-
4
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
JINCHEN
-
Product Name:
-
JCA SERIES
-
Structure:
-
Catridge
-
Size:
-
Customzised
-
Material:
-
Carbon Stee
-
Filter Type:
-
5 Micron Stainless Pleated Filter
PRODUCT DESCRIOTION
The JCS is a replacable core filter drier shell for use in large commercial air conditioning and refrigeration systems. The internal assembly allows the use of all kinds of Sanrong's replacable cores depending on the system requirements or application.
FEATURES
-
Compatible to R22, R134a, R410A, R407C, etc.
-
High moisture absorption, acid removal and filtering capacity
-
Power paint exterior coating surpasses 500-hour ASTM neutral salt spray test to resist corrosion
-
Slotted cover and unique internal hardware for hassle-free installation
-
Sturdy steel shells for long service life
-
Carbon finer reinforced PTFE gasket
-
Solid copper full-flow connections for low pressure drop
-
Optional 1/4" NPT pressure tapping
-
Max. working pressure of 4.5MPa / 650psig
-
UL, RoHS approved
SPECIFICATIONS
| Models | Conn. Size (inches) | No. of Cores |
Dimensions (inches) |
Liquid Flow Capacity (tons @ 1psi ΔP) |
||||||
| Qty x Size | A | B | C | D | R22 | R134a | R404A | R407C | ||
| JCA-485 | 5/8 ODF | 1 x 48in³ | 8.82 | 5.41 | 3.15 | 4.49 | 21 | 21 | 15 | 21 |
| JCA-487 | 7/8 ODF | 8.98 | 5.57 | 3.31 | 41 | 38 | 27 | 39 | ||
| JCA-489 | 1 1/8 ODF | 8.94 | 5.53 | 3.27 | 58 | 53 | 38 | 56 | ||
| JCA-4811 | 1 3/8 ODF | 9.19 | 5.79 | 3.52 | 81 | 75 | 53 | 78 | ||
| JCA-4813 | 1 5/8 ODF | 9.21 | 5.81 | 3.54 | 89 | 81 | 58 | 85 | ||
| JCA-4817 | 2 1/8 ODF | 9.41 | 6.12 | 3.50 | 101 | 93 | 66 | 97 | ||
| JCA-4821 | 2 5/8 ODF | 9.53 | 5.65 | 4.21 | 105 | 97 | 68 | 101 | ||
| JCA-4825 | 3 1/8 ODF | 10.00 | 5.85 | 4.21 | 119 | 110 | 77 | 114 | ||
| JCA-967 | 7/8 ODF | 2x48in³ | 14.69 | 11.28 | 3.31 | 45 | 42 | 27 | 43 | |
| JCA-969 | 1 1/8 ODF | 14.65 | 11.24 | 3.27 | 71 | 65 | 42 | 68 | ||
| JCA-9611 | 1 3/8 ODF | 14.90 | 11.50 | 3.52 | 87 | 80 | 54 | 83 | ||
| JCA-9613 | 1 5/8 ODF | 14.92 | 11.52 | 3.54 | 100 | 92 | 58 | 95 | ||
| JCA-9617 | 2 1/8 ODF | 15.12 | 11.71 | 3.50 | 104 | 96 | 68 | 100 | ||
| JCA-9621 | 2 5/8 ODF | 15.24 | 11.18 | 4.21 | 109 | 101 | 71 | 105 | ||
| JCA-9625 | 3 1/8 ODF | 15.35 | 11.20 | 4.21 | 125 | 116 | 81 | 120 | ||
| JCA-1449 | 1 1/8 ODF | 3x48in³ | 20.28 | 16.87 | 3.27 | 72 | 66 | 47 | 69 | |
| JCA-14411 | 1 3/8 ODF | 20.53 | 17.13 | 3.52 | 100 | 92 | 65 | 96 | ||
| JCA-14413 | 1 5/8 ODF | 20.55 | 17.15 | 3.54 | 101 | 93 | 66 | 97 | ||
| JCA-14417 | 2 1/8 ODF | 20.67 | 17.38 | 3.50 | 120 | 110 | 78 | 115 | ||
| JCA-19211 | 1 3/8 ODF | 4x48in³ | 26.44 | 23.03 | 3.52 | 102 | 94 | 67 | 98 | |
| JCA-19213 | 1 5/8 ODF | 26.46 | 23.05 | 3.54 | 113 | 103 | 74 | 108 | ||
| JCA-19217 | 2 1/8 ODF | 26.57 | 23.29 | 3.50 | 123 | 113 | 80 | 117 | ||
| JCA-19221 | 2 5/8 ODF | 26.85 | 23.44 | 4.21 | 131 | 121 | 85 | 126 | ||
| JCA-20034 | 4 1/4 ODF | 2x100in³ | 17.95 | 12.64 | 5.28 | 6 | 149 | 138 | 98 | 146 |
| JCA-30013 | 1 5/8 ODF | 3x100in³ | 23.98 | 19.25 | 4.30 | 110 | 102 | 73 | 108 | |
| JCA-30017 | 2 1/8 ODF | 24.13 | 19.41 | 4.50 | 160 | 148 | 107 | 157 | ||
| JCA-30021 | 2 5/8 ODF | 24.57 | 19.88 | 4.97 | 168 | 155 | 111 | 165 | ||
| JCA-30025 | 3 1/8 ODF | 24.57 | 19.88 | 4.97 | 182 | 168 | 120 | 178 | ||
| JCA-30034 | 4 1/4 ODF | 24.25 | 18.94 | 5.28 | 198 | 183 | 131 | 194 | ||
| JCA-40017 | 2 1/8 ODF | 4x100in³ | 31.81 | 27.09 | 4.50 | 170 | 157 | 114 | 167 | |
| JCA-40021 | 2 5/8 ODF | 32.24 | 27.52 | 4.97 | 180 | 166 | 120 | 177 | ||
If you need more details about this product, please feel free to contact us.
