Quick Details
-
Dimension(L*W*H):
-
400*325*340mm
-
Weight:
-
33kg
-
Warranty:
-
1 Year
-
Certification:
-
ISO
-
color:
-
as you need
Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
oem
-
Model Number:
-
170F
-
Dimension(L*W*H):
-
400*325*340mm
-
Weight:
-
33kg
-
Warranty:
-
1 Year
-
Certification:
-
ISO
-
color:
-
as you need
|
Model |
FSH170F(E) |
FSH178F(E) |
FSH178FA(E) |
FSH186F(E) |
FSH186FA(E) |
|
Type |
Air-cooled,4-stroke,single cylinder,side valve |
||||
|
Bore*storke(mm) |
70*55 |
78*62 |
78*64 |
86*70 |
86*75 |
|
Dispalcement(L) |
0.211 |
0.296 |
0.305 |
0.406 |
0.418 |
|
Combustion sysytem |
Derict injection |
||||
|
Rate output KW(HP)/rpm |
2.5(3.4)/3000
|
3.8(5.1)/3000
|
3.8(5.1)/3000
|
5.7(7.75)/3000
|
5.7(7.75)/3000
|
|
Max output KW(HP)/rpm |
2.8(3.8)/3000
|
4.0(5.36)/3000
|
4.0(5.36)/3000
|
6.3(8.57)/3000
|
6.3(8.57)/3000
|
|
Direction of rotation |
Counterclockwise,facing PTOshaft |
||||
|
Fuel |
0#(summer)/-10#(winder) |
||||
|
Fule tank capacity(L) |
2.5 |
3.5 |
3.5 |
5.5 |
5.5 |
|
Lubricationg oil capacity(L) |
0.75 |
1.1 |
1.1 |
1.65 |
1.65 |
|
Lubricationg system |
Pressure splashed |
||||
|
Start system |
Recoil starter/Electric start |
||||
|
Packing size(L*W*H)mm |
415*385*470 |
485*475*525 |
485*475*525 |
500*470*555 |
500*470*555 |
|
20FT unit |
312 |
220 |
220 |
192 |
192 |
|
Net weight(KG) |
26 |
35 |
35 |
48 |
48 |
