Quick Details
-
Panel Dimensions:
-
1755*1038*35mm
-
Panel Efficiency:
-
370 watt
-
Solar cell:
-
Mono 182x182mm
-
Warranty:
-
25 Years Output Power Guarantee
-
Frame:
-
Anodized Aluminium Alloy
-
Connector:
-
Solar connector
-
Color:
-
Black Blue
-
Junction Box:
-
IP65 Rated
-
Front Cover:
-
3.2mm High transmission, low Iron
-
Size:
-
1755*1038*35mm
-
Certificate:
-
TUV/CE/ETL/Inmetro/CEC
Quick Details
-
Brand Name:
-
Solar home
-
Model Number:
-
BSM370M-60HPH
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
1755*1038*35mm
-
Panel Efficiency:
-
370 watt
-
Solar cell:
-
Mono 182x182mm
-
Warranty:
-
25 Years Output Power Guarantee
-
Frame:
-
Anodized Aluminium Alloy
-
Connector:
-
Solar connector
-
Color:
-
Black Blue
-
Junction Box:
-
IP65 Rated
-
Front Cover:
-
3.2mm High transmission, low Iron
-
Size:
-
1755*1038*35mm
-
Certificate:
-
TUV/CE/ETL/Inmetro/CEC
Who Buy From Bluesun
Products Description
Perc Cell
The PERC cell has a passivated rear side and a laser grooving process, which significantly improves the cell efficiency.
Technical Specification
|
Electrical Characteristics AT STC
|
|
|
|
|
|
|
||||||
|
Model Number
|
BSM355M-60HPH
|
BSM360M-60HPH
|
BSM365M-60HPH
|
BSM370M-60HPH
|
BSM375M-60HPH
|
BSM380M-60HPH
|
||||||
|
Maximum Power (Pmax/W)
|
355
|
360
|
365
|
370
|
375
|
380
|
||||||
|
Open Circuit Voltage (Voc/V)
|
40.5
|
40.7
|
40.9
|
41.1
|
41.3
|
41.5
|
||||||
|
Short Circuit Current (Isc/A)
|
11.10
|
11.15
|
11.20
|
11.26
|
11.31
|
11.36
|
||||||
|
Voltage at Maximum Power (Vmp/V)
|
34.0
|
34.3
|
34.6
|
34.9
|
35.2
|
35.5
|
||||||
|
Current at Maximum Power (Imp/A)
|
10.45
|
10.50
|
10.56
|
10.61
|
10.66
|
10.71
|
||||||
|
Module Efficiency)%)
|
19.3
|
19.6
|
19.8
|
20.1
|
20.4
|
20.8
|
||||||
|
Power Tolerance
|
0-5W
|
|
|
|
|
|
||||||
|
Max System Voltage
|
DC 1500/1000(1 EC)
|
|
|
|
|
|
||||||
|
Max Series Fuse Rating
|
20A
|
|
|
|
|
|
||||||
|
Operating Temperature
|
-40 C to + 85 C
|
|
|
|
|
|
||||||
|
STC
|
Irradiance 1000W/m2, cell temperature 25C, AM 1.5
|
|
|
|
|
|
||||||
