Quick Details
-
Model Number:
-
EPL
-
Protection Level:
-
IP65
-
Operating Temperature:
-
-20~60℃
-
Max. Current:
-
3A
-
Product name:
-
safety door switch
-
Certificates:
-
Yes
-
Rated insulation voltage:
-
300v
-
Warranty:
-
1 Year
-
Condition:
-
100% Brand-new
-
Production time:
-
3-7 days
-
Contacts type:
-
1NC/1NO
-
Key inserting direction:
-
front side of switch
-
Nominal discharge current (lth):
-
10A
-
Direct open force:
-
>60N
Quick Details
-
Max. Voltage:
-
250V
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
ESPE brand
-
Model Number:
-
EPL
-
Protection Level:
-
IP65
-
Operating Temperature:
-
-20~60℃
-
Max. Current:
-
3A
-
Product name:
-
safety door switch
-
Certificates:
-
Yes
-
Rated insulation voltage:
-
300v
-
Warranty:
-
1 Year
-
Condition:
-
100% Brand-new
-
Production time:
-
3-7 days
-
Contacts type:
-
1NC/1NO
-
Key inserting direction:
-
front side of switch
-
Nominal discharge current (lth):
-
10A
-
Direct open force:
-
>60N
Welcome to ESPE! New Original Vertical Safety Door Limit Switch IP67 Protection Grade Bloqueo Electromagnetic
Here we just show an example, please contact us for more models.
You're special for us and deserve our special customization service.
. Cost-effective to save your money
. Quick lead time to ensure your delivery
. ODM & OEM service to ensure suitable model
. Professional technical service support
. 19 years experience and Chinese top 2 factory ensure your quality
| Item | Value | ||
| Model | EPL ,EPS ,EPM ,EPC | ||
| Housing material | PA66 fire retardant material | ||
| Contact material | Gold plating silver alloy | ||
| Protection degree | IP 67(EN 60947 - 5 -1,Except key hold) | ||
| Durability | Mechanical:1000000 min/ Electrical:150000 min | ||
| Holding force | 1300N | ||
| Rated insulation voltage(Ui) | 300V | ||
| Rated impulse withstand voltage(Uimp) | 2.5KV | ||
| Nominal discharge current(lth) |
10A |
||
| Voltage type | AC -15 | DC - 13 | |
| Rated operating voltage(Ue) | 240V | 30V | 250V |
| Rated operating current(le) | 3A | 2.3A | 0.27A |
| Conditional short-current | 1000A | ||
