- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
WERNER
-
Model Number:
-
DW60A
-
Certification:
-
ISO,CE
Quick Details
-
Rated Voltage:
-
24V
-
Rated Current:
-
200A
-
Frequency:
-
DC
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
WERNER
-
Model Number:
-
DW60A
-
Certification:
-
ISO,CE
| DC generator | ||
| GENSET MODEL | Open type model | DW60A |
| Soundproof model | DW60A/S | |
| Continuous output(kw/hp) | 5KW/6.7 | |
| DC Voltage(V) | 24V | |
| DIESEL ENGINE MODEL | 188FB | |
| Engine Characters | 1-cylinder ,vertical 4-stroke,air-cooled,diesel | |
| Rated power/speed (KW/rpm) | 8.3/3000 | |
| Displacement(cc) | 456 | |
| Compression ratio | 20.5 | |
| Max. torque (N.M) | 52/2000-2100 | |
| Lubricating system | Pressure splashed | |
| Starting system | Eleoctric start | |
| Direction of rotation | Counterclockwise viewed from PTO side | |
| Fuel consumption rate (g/kw.h)Max | 295 | |
| Lube oil brand | SAE10W-30 or 15W-40 | |
| Lube oil capacity (L) | 1.65 | |
| ALTERNATOR MODEL | W60A | |
| Continuous output(kw) | 5 | |
| Power Efficiency | ≥90% | |
| Voltage Regulation | 24V+ 5% adjustment | |
| Wave form | DC Wave | |
| Max Current (A) | 300 | |
| Ripple voltage | ≤3mV | |
| Dimension(mm*mm*mm) silent | 800*530*700 | |
Design and invent patent
Working curve:
