Quick Details
-
Product Name:
-
Gym Locker Lock
-
Material of lock body:
-
ABS+PC
-
Tensile strength:
-
200 kg
-
Power consumption:
-
2.2W
-
Working voltage:
-
8V~24V
-
Working current:
-
220mA@10V
-
Protection level:
-
IP66
-
Application:
-
self service locker; pick up station; temporary locker; etc
-
Certification:
-
RoHS, CE, FCC
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
KERONG
-
Model Number:
-
KR-S98S
-
Product Name:
-
Gym Locker Lock
-
Material of lock body:
-
ABS+PC
-
Tensile strength:
-
200 kg
-
Power consumption:
-
2.2W
-
Working voltage:
-
8V~24V
-
Working current:
-
220mA@10V
-
Protection level:
-
IP66
-
Application:
-
self service locker; pick up station; temporary locker; etc
-
Certification:
-
RoHS, CE, FCC
Product Parameters
|
Brand
|
|
|
KERONG
|
|
|
||||
|
Product Model
|
|
|
KR-S98S
|
|
|
||||
|
Product Name
|
|
|
Gym Locker Lock
|
|
|
||||
|
Material
|
|
|
ABS+PC
|
|
|
||||
|
Size
|
|
|
98*66* 14.5 mm
|
|
|
||||
|
Weight of Lock
|
|
|
104 g
|
|
|
||||
|
Colour
|
|
|
Black
|
|
|
||||
|
Surface Treatment
|
|
|
Mold texture surface
|
|
|
||||
|
Working Temperature
|
|
|
-20℃～+60℃
|
|
|
||||
|
Working Humidity
|
|
|
5%~85%RH
|
|
|
||||
|
Application
|
|
|
Gym Locker, Electric Cabinet, Parcel Storage Locker, Supermarket Locker, etc
|
|
|
||||
|
Working Life
|
|
|
200,000 times
|
|
|
||||
|
Detective Switch
|
|
|
Omron
|
|
|
||||
|
Drive Mode
|
|
|
Motor
|
|
|
||||
|
Certifications
|
|
|
CE, RoHS, FCC
|
|
|
||||
Product Specification
• AWG24 wires with PVC protecting tube.
• Support customizing wires and connectors.
• IP66. All electronic parts are protected with the sealed ABS box.
• Omron micro detective switch from Japan with high quality and durability.
• Mechanical emergency lever, can be unlocked manually in case of power failure .
• Driven by motor, wide working voltage range: 8~24V. Low power consumption.
• It is recommended that the user's power supply unlocking time is greater than 500ms (without interruption).
• Support customizing wires and connectors.
• IP66. All electronic parts are protected with the sealed ABS box.
• Omron micro detective switch from Japan with high quality and durability.
• Mechanical emergency lever, can be unlocked manually in case of power failure .
• Driven by motor, wide working voltage range: 8~24V. Low power consumption.
• It is recommended that the user's power supply unlocking time is greater than 500ms (without interruption).
