Quick Details
-
Brand Name:
-
SoluGET
-
Medium:
-
PP
-
Support and drainage:
-
PP
-
Core, cage, and end caps:
-
PP
-
Length:
-
5inch,10inch,20inch,30inch,40inch
-
Removal Ratings:
-
0.1um,0.45um,1um,3um,5um
-
O-ring options:
-
Silicone FKM EPDM NBR FEP Encapsulated Silicone FEP Encapsulated FKM
-
Diameter (OD):
-
68 mm,83 mm
-
Maximum Operating Temperature:
-
82℃
-
Maximum Operating Pressure Differential:
-
0.38MPa/21℃ 0.24MPa/80℃
-
Certificate:
-
ISO9001 & ISO14001
Quick Details
-
Weight (KG):
-
0.9
-
Core Components:
-
Filter
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
SoluGET
-
Medium:
-
PP
-
Support and drainage:
-
PP
-
Core, cage, and end caps:
-
PP
-
Length:
-
5inch,10inch,20inch,30inch,40inch
-
Removal Ratings:
-
0.1um,0.45um,1um,3um,5um
-
O-ring options:
-
Silicone FKM EPDM NBR FEP Encapsulated Silicone FEP Encapsulated FKM
-
Diameter (OD):
-
68 mm,83 mm
-
Maximum Operating Temperature:
-
82℃
-
Maximum Operating Pressure Differential:
-
0.38MPa/21℃ 0.24MPa/80℃
-
Certificate:
-
ISO9001 & ISO14001
Product Description
Specification
|
Material Structure
|
|
|
|
Medium
|
PP
|
|
|
Support and drainage
|
PP
|
|
|
Core, cage, and end caps
|
PP
|
|
|
Operating Characteristics
|
|
|
|
Maximum Operating Temperature
|
82℃
|
|
|
Maximum Operating Pressure Differential
|
0.38MPa/21℃
0.24MPa/80℃ |
|
|
Filter Cartridge Selection Chart
|
|
|
|
|
||||
|
HCPP
|
Removal Ratings
|
Length
|
Connector
|
O-ring options
|
||||
|
|
0.1um
|
5inch
|
DOE=double open ended
|
Silicone
|
||||
|
|
0.45um
|
10inch
|
C3=222+flat closed end
|
FKM
|
||||
|
|
1um
|
20inch
|
C8=222+fin end
|
EPDM
|
||||
|
|
3um
|
30inch
|
C2=226+flat closed end
|
NBR
|
||||
|
|
5um
|
40inch
|
C7=226+fin end
|
FEP Encapsulated Silicone
|
||||
|
|
|
|
|
FEP Encapsulated FKM
|
||||
