spices/ pepper/ chili grinding machine

Raw material :

Grain Milling Machine/ spice grinding machine/Grain Grinding Machine we manufactured widely used in kinds of spices ,seasonings ,cacao, soybean, pepper , chilli ,buckwheat , black kerneled rice / rice / brown rice / mung bean / black soya bean / peanut / lotus seeds / corn / broomcorn / barley / oats / purple rice / sticky rice / millet / ormosia / bright rice / Gordon Euryale Seed / Dioscorea opposita Thunb / the root of kudzu vine / Radix Angelicae Dahuricae / Poria cocos / star aniseed powder / tea leaves / fructus amomi / white sugar / salt / i n addition, it can also be used in milling rice, oat, corn...etc.

When working, it relies on the millstones to make the goods into powder. This machine can realize continuous feed-type operation. Its unique design, low noise level, easy operation, crushed fine, dust-free have won lots of praise of our customer. It is a good choose for supermarket, store, processing shop...etc. Made of stainless steel, this type machine can realize durable use life.

Working principle:
Connecting shaft and motor shaft is directly connected, when the motor starts running, drive the connecting shaft and the disc in connection axis operate together. Material from the hopper into the mill set to be grinding, the relative operation of the lap spindle and milling sets, breaking force make the material minced into small pieces particles.

Minced after the small particles are brought into the middle of the two grinding by spiral motion of the disc, the relative operation of the grinding tooth pattern made the material in a short time be crushed into small particles (powder). The powder from the grinding of the teeth ditch outflow four weeks, to be taken off by scraping powder board loaded in the disc and out of the powder outlet.

characteristics:

1.The powder outlet fitted with four magnetic devices, adsorption machine operation the process of grinding the iron pad wear, ensuring food hygiene and safety;

2. The connecting shaft is shorter, and disassembly easy.

3. One-time stamping of the Department of stainless steel hopper shape, no solder joints, more luxurious, more beautiful, more health!

4. Both sides of the motor cover has six rows of cooling holes, First, conducive to the motor cooling to protect the motor; reduce the resonance due to the sealing, the vibration is smaller.

machine parameters
