XRF Analyzer Price Three Element Xray Detector Portable Heavy Metal Gold Spectrometer 24 Carat Nondestructive Tester

TrueX 800 elements analyzed

Scope of elements in standard test mode can be extended if there is such a need.

TrueX 800

can analyze Ti, V, Cr, Mn, Fe, Co, Ni, Cu, Zn, Se, Zr, Nb, Mo, Rh, Pd, Ag, Cd, Sn, Sb, Hf, Ta, W, Re, Pb, and Bi,totaling 25
elements.

Weight

1.6Kg（with battery）.

Dimensions

254 x 79 x 280 mm（L x W x H）.

Excitation source

50KV/200μA maximum pipe pressure pipe flow can be adjusted freely,Agtarget (standard),Au,W,Rh target(optional).

Detector

BOOST Si-PIN detector

Range of detection

All elements between Mg and U.

Display system

Industrial resistive touch screen with screen size of 4.3".
Proprietary operating system software and sound waves.
Multiple languages including English and Chinese.
And it automatically adjusts display brightness according to the environment brightness.

Data processing

32GB memory
USB, bluetooth, WIFI, or liked to the Internet; instrument can be
configured and repaired remotely.
Data can be exported via EXCEL or PDF. Users can customize the
reports by adding their company logos, addresses, test results,
spectrum and others (such as product description, origin and batch
number).

Heat dissipation

Equipped with a dedicated T-shaped radiator to dissipate the heat；no need to wait for cooling of detector time again.

Safety

Built-in double beam technology can automatically sense whether
there is a sample at the measurement window. This is also a safety and protection feature.
Waterproof, dust-proof and shockproof suitcase
Drawell Safety Band；

Power supply system

Intelligent battery management through MSBUS bus, real-time
monitoring of the residual capacity of battery and backup battery. The battery complies with air transport regulations of
dangerous goods.
A single battery can last 8 hours.
