Quick Details
-
Model Number:
-
EEL-A01
-
Place of Origin:
-
Guangdong, China
-
Nominal Voltage:
-
48V/51.2V
-
Battery cell:
-
LiFePO4
-
Features:
-
Stackable
-
Application:
-
Solar Energy Storage Systems/Electric Power Systems
-
OEM/ODM:
-
Support customization
-
Sample::
-
Acceptable
-
Communication::
-
CANBUS and RS485
-
BMS::
-
48V 16S 100A/150A/200A BMS
-
Warranty::
-
3 years
Quick Details
-
Brand Name:
-
EEL 48V DIY Kit
-
Certification:
-
CE, CE/RoHS/UN38.3/MSDS/ISO
-
Material:
-
iron
-
Model Number:
-
EEL-A01
-
Place of Origin:
-
Guangdong, China
-
Nominal Voltage:
-
48V/51.2V
-
Battery cell:
-
LiFePO4
-
Features:
-
Stackable
-
Application:
-
Solar Energy Storage Systems/Electric Power Systems
-
OEM/ODM:
-
Support customization
-
Sample::
-
Acceptable
-
Communication::
-
CANBUS and RS485
-
BMS::
-
48V 16S 100A/150A/200A BMS
-
Warranty::
-
3 years
Tips:
This item is Battery Box, BMS and other necessary stuffs to build a battery pack,not including battery cells. BMS with bluetooth Module and RS485 cable.
Shipping is DDP service including all tax duty fees.
1.200A BMS B
uilt-in (Optional 100A 150A 200A BMS)
2. 51.2V 200Ah 230Ah 280Ah 300Ah 320Ah DIY Battery Kit.
3. Max 15pcs can be supported in tandem by the BMS.
4. Bluetooth APP control is supported by BMS
5. Support brands for inverters: GOODEWE, DEYE, SUNRE, GRWATT...
6. Able to alter your LOGO and offer OEM support
7. Our bespoke items are produced in a plant in China, and sample delivery for them takes 15 days. We offer European warehouse services in both Europe and the United States.
8. We also provide whole battery pack.
Product Paramenters
|
Item
|
General Parameters
|
|
Model
|
EEL V4 DIY Battery Case
|
|
Nominal Voltage
|
51.2V
|
|
Nominal Capacity
|
200/230/280/302/304/310/320AH
|
|
Supported battery models
|
CATL/CALB/E-VE 280AH/302AH/304AH
|
|
Max Charge Voltage
|
58.4V
|
|
Cut-off Discharge Voltage
|
40V
|
|
Standard Charge Float Voltage
|
55.2V
|
|
Max 10sec. Pulse Current
|
380A
|
|
Max. Continuous Discharge Current
|
200A
|
|
Max Charge Current
|
200A
|
|
Recommended Current
|
140A (25±2℃)
|
|
Weight (Approximate)
|
29KG
|
|
Dimensions (L*W*H)
|
L69.8*W41*H25cm
|
|
Operating Temperature
|
Charging: -20~60℃/Discharging: -30~60℃
|
|
Application
|
Power Storage System, Electric vehicles, Golf carts and so on
|
Battery Accessories
Note:
Our kits are equipped with a BMS that is
CAN and 485
communication compatible and can be matched to most brands of inverters on the market without complicated commissioning.
