Quick Details
-
Pulse Frequency:
-
50-60HZ
-
Pilot Arc Current:
-
125-220A
-
Rated Duty Cycle:
-
60%
-
Dimensions:
-
35*15.5*24CM
-
Usage:
-
Welding
-
Voltage:
-
220V, 220V
-
Power:
-
6-8KVA
-
Weight (KG):
-
4.2 KG
-
Color:
-
Customized Color
-
Efficiency:
-
80%
-
Function:
-
Arc DC Welding Machine
-
Key words:
-
Arc Welding Machine
-
Package:
-
Carton Package
-
Feature:
-
Energy-saving
-
Cover:
-
IRON
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Shenglang
-
Arc Current:
-
125-220A
-
Pulse Frequency:
-
50-60HZ
-
Pilot Arc Current:
-
125-220A
-
Rated Duty Cycle:
-
60%
-
Dimensions:
-
35*15.5*24CM
-
Usage:
-
Welding
-
Voltage:
-
220V, 220V
-
Power:
-
6-8KVA
-
Weight (KG):
-
4.2 KG
-
Color:
-
Customized Color
-
Efficiency:
-
80%
-
Function:
-
Arc DC Welding Machine
-
Key words:
-
Arc Welding Machine
-
Package:
-
Carton Package
-
Feature:
-
Energy-saving
-
Cover:
-
IRON
| Model | ARC-200 | ARC-250 | ARC-300 | ARC-315 | ARC-400 |
| Intput voltage(V) | 220V | 220/380V | 220V | 220/380V | 220/380V |
| Frequency(Hz) | 50-60HZ | 50-60HZ | 50-60HZ | 50-60HZ | 50-60HZ |
| Rated input capacity(KVA) | 6 | 7.5 | 8 | 10 | 14.4 |
| Max no-load voltage(V) | 62 | 62 | 62 | 62 | 62 |
| Current range (A) | 20-200 | 20-250 | 20-300 | 20-315 | 20-400 |
| Rated Duty Cycle(%) | 60 | 60 | 60 | 60 | 60 |
| Welding rod size(MM) | 1.6-3.2 | 1.6-3.2 | 1.6-4 | 1.6-4 | 1.6-5 |
| Protection degree | IP21S | IP21S | IP21S | IP21S | IP21S |
| Weight (KG) | 3.5-4.3 | 4-6.5 | 4.2-4.3 | 9.5 | 12.5 |
| Dimension (CM) | 33*13*20.5 | 35*15.5*24 | 35*15.5*24 | 41*23*27 | 42*23*29 |
Product Description
1. With automatic compensation for voltage fluctuations capacity, anti-network fluctuation strong, stable welding current;
2. With automatic over-voltage over-current protection function;
3. A good thrust compensation, dynamic characteristics, and flying small, high efficiency, weld appearance;
4. Through pulse width modulation(PWM) output power DC source, stable performance, small size, light weight, energy-saving , above 30% more efficient than traditional welding efficiency;
5. Current continuously adjustable, easy to use;
6. Suitable for all kinds of electrode welding.
