21.2 %
Maximum Module Efficiency
Explore More Products
- Product Details
- {{item.text}}
Quick Details
-
Warranty:
-
30 YEARS
-
Brand Name:
-
QCells
-
Model Number:
-
Q.PEAK All Black 385-410W
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
1879 mm x 1045 mm x 32 mm
-
Cells Layout:
-
6 x 22 monocrystalline Q.ANTUM solar half cells
-
Weight:
-
22.0kg
-
Glass:
-
3.2.0mm Coated Tempered Glass
-
Junction box:
-
IP67, with bypass diodes
-
Cable:
-
4 mm2 Solar cable
-
Back Cover:
-
Composite film
-
Wind/Snow Load:
-
113 (5400 Pa)/ 84 (4000 Pa)
-
Operate Temperature:
-
-40C~ +85C
-
Maximum system Voltage:
-
1000 (IEC)
-
Fire Rating:
-
ANSI UL 61730 TYPE 2
Quick Details
-
Cell size:
-
158.75mmx158.75mm
-
Type:
-
PERC, Half Cell, Bifacial, Double-glass, All Black, IBC, HJT, hbc, N-TYPE, TOPCON
-
Panel Efficiency:
-
21.1%
-
Warranty:
-
30 YEARS
-
Brand Name:
-
QCells
-
Model Number:
-
Q.PEAK All Black 385-410W
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
1879 mm x 1045 mm x 32 mm
-
Cells Layout:
-
6 x 22 monocrystalline Q.ANTUM solar half cells
-
Weight:
-
22.0kg
-
Glass:
-
3.2.0mm Coated Tempered Glass
-
Junction box:
-
IP67, with bypass diodes
-
Cable:
-
4 mm2 Solar cable
-
Back Cover:
-
Composite film
-
Wind/Snow Load:
-
113 (5400 Pa)/ 84 (4000 Pa)
-
Operate Temperature:
-
-40C~ +85C
-
Maximum system Voltage:
-
1000 (IEC)
-
Fire Rating:
-
ANSI UL 61730 TYPE 2
Products Description
|
Power at MPP1
|
PMPP
|
[W]
|
385
|
390
|
395
|
400
|
405
|
410
|
|
Short Circuit Current1
|
ISC
|
[A]
|
11.04
|
11.07
|
11.10
|
11.14
|
11.17
|
11.20
|
|
Open Circuit Voltage1
|
VOC
|
[V]
|
45.19
|
45.23
|
45.27
|
45.30
|
45.34
|
45.37
|
|
Current at MPP
|
IMPP
|
[A]
|
10.59
|
10.65
|
10.71
|
10.77
|
10.83
|
10.89
|
|
Voltage at MPP
|
VMPP
|
[V]
|
36.36
|
36.62
|
36.88
|
37.13
|
37.39
|
37.64
|
|
Efficiency1
|
η
|
[%]
|
≥ 19.6
|
≥ 19.9
|
≥ 20.1
|
≥ 20.4
|
≥ 20.6
|
≥ 20.9
|
Products Series
Q.PEAK DUO-G10
360 - 380 Wp
| 120 Cells
385 - 410 Wp
| 132 Cells
20.9 %
Maximum Module Efficiency
395 - 415 Wp
| 132 Cells
21.1 %
Maximum Module Efficiency
475 - 495 Wp
| 156 Cells
21.4 %
Maximum Module Efficiency
475 - 490 Wp
| 156 Cells
21.2 %
Maximum Module Efficiency
570 - 585 Wp
| 156 Cells
21.4 %
Maximum Module Efficiency
