- Product Details
- {{item.text}}
Quick Details
-
Application:
-
Apartment
-
Design Style:
-
Industrial
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
HY
Quick Details
-
Warranty:
-
5 years
-
After-sale Service:
-
Online technical support
-
Project Solution Capability:
-
total solution for projects
-
Application:
-
Apartment
-
Design Style:
-
Industrial
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
HY
Product Description
Specification
item
|
value
|
Type
|
Geomembranes
|
Warranty
|
More than 5 years
|
After-sale Service
|
Online technical support
|
Project Solution Capability
|
total solution for projects
|
Application
|
Fish Shrimp Farm Pond
|
Design Style
|
Smooth
|
Place of Origin
|
China
|
|
Shandong
|
Brand Name
|
HAOYANG
|
Model Number
|
GM13
|
Material
|
HDPE LDPE LLDPE EPDM EVA
|
Product Name
|
Smooth Geomembrane
|
Thickness
|
1.5mm
|
Width
|
9.5m
|
Length
|
50-200m
|
Color
|
Black White Blue Green (customized)
|
Application
|
Fish Shrimp Farm Pond
|
Density
|
0.940g/cm3
|
Delivery
|
Within 10 Days
|
Standard
|
ASTM GRI-GM13
|
Product introduction
Geomembrane is a polymer film used in engineering and environmental applications, typically made from plastic materials such as polyethylene (HDPE),etc. It has the functions of waterproofing, impermeability, isolation and protection, and is widely used in various engineering projects and environmental protection.
Geomembrane plays an important role in the field of environmental protection and basic engineering, and can effectively improve the stability of engineering structures and protect the environment. Choosing the right material and correct construction method is crucial for geomembrane to play the best role.
Haoyang Environment is a professional supplier of geomembrane, with the country's largest radius of geomembrane production equipment and a variety of production lines, is one of the main suppliers of China's South-to-North water diversion project.
Manufacturing Technique
How is geomembrane produced?
Geomembrane is formed through the extrusion production process, the specific steps are as follows:
Product Paramenters
Common HDPE geomembrane (GH-1 type) technical performance index GBT17643-2011
The data in the National standard form is based on the results of professional testing and specification development and represents the key performance, quality standards or technical requirements of the products or services in the industry. This data typically includes a variety of indicators, parameters, and specifications that are used to assess the safety, reliability, and conformity of the product.
Our company's products are strictly in accordance with the national standard or even beyond the national standard for production and manufacturing, quality control standards are higher than the national standard, our each batch of products have passed the strict laboratory instrument testing before they will be sold.
No.
|
Item
|
Unit
|
Index
|
|
|
|
|
|
|
||||||||
1
|
Thickness
|
mm
|
0.30
|
0.50
|
0.75
|
1.00
|
1.50
|
2.00
|
3.00
|
||||||||
2
|
Density
|
g/cm3
|
≧0.940
|
|
|
|
|
|
|
||||||||
3
|
Tensile yield strength
|
N/mm
|
≧4
|
≧7
|
≧10
|
≧10
|
≧20
|
≧26
|
≧40
|
||||||||
4
|
Tensile breaking strength
|
N/mm
|
≧6
|
≧10
|
≧15
|
≧20
|
≧30
|
≧40
|
≧60
|
||||||||
5
|
Yield elongation
|
%
|
-
|
-
|
-
|
≧11
|
|
|
|
||||||||
6
|
Break Elongation
|
%
|
≧600
|
|
|
|
|
|
|
||||||||
7
|
Right-angle
Tearing strength |
N
|
≧34
|
≧56
|
≧84
|
≧115
|
≧170
|
≧225
|
≧340
|
||||||||
8
|
Puncture
strength |
N
|
≧72
|
≧120
|
≧180
|
≧240
|
≧360
|
≧480
|
≧720
|
||||||||
9
|
Carbon black content
|
%
|
2.0~3.0
|
|
|
|
|
|
|
||||||||
10
|
Dispersion
of carbon black |
-
|
here is not more than one level 3 in 10 data, and level 4 and level 5 are not allowed to exist.
|
|
|
|
|
|
|
||||||||
11
|
Oxidation induction time
|
min
|
≧60
|
|
|
|
|
|
|
||||||||
12
|
Low temperature impact embrittlement properties
|
-
|
Pass
|
|
|
|
|
|
|
||||||||
13
|
Water vapor permeability coefficient
|
g.cm/
(cm2.s.Pa) |
≦1.0*10-13
|
|
|
|
|
|
|
||||||||
14
|
Dimensional stability
|
%
|
±2.0
|
|
|
|
|
|
|
||||||||
Note
|
Technical performance indicators for thickness specifications not listed in the table are required to be performed by
interpolation. |
|
|
|
|
|
|
|
|
Applications
Geomembrane has a wide range of application fields, mainly including but not limited to the following aspects:
(1)Waterproof works: Waterproof barriers for all kinds of engineering projects, such as basements, tunnels, reservoirs, river embankments and water conservancy projects, effectively prevent water penetration and leakage.
(2)Soil isolation: Used to isolate different soil layers or to stop contaminants from seeping into groundwater, such as in landfills, chemical plants, and wastewater treatment facilities.
(3)Soil stabilization and reinforcement: Used for the reinforcement and stabilization of soil, used in roads, railways, airports, retaining walls and land backfill and other engineering projects to enhance the stability and bearing capacity of the structure.
(4)Environmental protection: Used for environmental remediation and protection works to close or isolate contaminated land areas to prevent the spread of pollutants.
(5)Hydraulic engineering: In coastal protection, DAMS, water channels and artificial islands and other hydraulic engineering, to prevent water infiltration and erosion.
(6)Landscape design: Applied in landscape and landscape design as ground cover material, protect soil and vegetation, control water penetration.
(7)Mining and industrial applications: Used in mines, chemical plants and industrial facilities as an impermeable layer to prevent waste or harmful substances from leaking and protect the environment.
