Quick Details
-
Panel Dimensions:
-
1979*1002*35mm
-
Panel Efficiency:
-
21.98%
Quick Details
-
Brand Name:
-
Yangtze
-
Model Number:
-
YS400M-BI
-
Place of Origin:
-
China
-
Panel Dimensions:
-
1979*1002*35mm
-
Panel Efficiency:
-
21.98%
Product Description
|
Model Type
|
YS200M-BI
|
YS560M-72
|
YS300M-BI
|
YS580M-72
|
YS400M-BI
|
|||||
|
Rated Maximum Power at STC
|
200W
|
560W
|
300W
|
580W
|
400W
|
|||||
|
Maximum Power Voltage (Vmp)
|
28.5V
|
41.1V
|
33.2V
|
41.5V
|
34.82V
|
|||||
|
Maximum Power Current (Imp)
|
7.02A
|
13.63A
|
9.03A
|
13.98A
|
11.49A
|
|||||
|
Open Circuit Voltage ( Voc)
|
35.63V
|
49.72V
|
41.5V
|
49.91V
|
43.53V
|
|||||
|
Short Circuit Current (Isc)
|
7.51A
|
14.33A
|
9.69A
|
14.81A
|
12.64A
|
|||||
|
Module Efficiency
|
14.90%
|
21.72%
|
18.44%
|
22.49%
|
21.98%
|
|||||
|
Working Conditions&Working Conditions
|
|
|
|
|
|
|||||
|
Glass Thickness
|
|
2mm 4mm 6mm 8mm 10mm 12mm
|
|
|
|
|||||
|
Transmittance
|
|
10% 20% 30% 40% 50% 60% 70% 80%
|
|
|
|
|||||
|
Operating Temperature
|
|
-40°c~+85°c
|
|
|
|
|||||
|
Maximum System Voltage
|
|
DC 1000V(IEC) / 1500V(IEC)
|
|
|
|
|||||
|
Maximum Series Fuse
|
|
25A
|
|
|
|
|||||
|
Power Tolerance
|
|
0~+5W
|
|
|
|
|||||
|
Temperature Coefficient of Pmax
|
|
-0.35%/°c
|
|
|
|
|||||
|
Temperature Coefficient of Voc
|
|
-0.29%/°c
|
|
|
|
|||||
|
Temperature Coefficient of Isc
|
|
+0.048%/°c
|
|
|
|
|||||
|
STC
(Standard Testing Conditions): lrradiance 1000W/m2 , Cell Temperature 25 'C, Spectra at AMl.5
|
|
|
|
|
|
|||||
|
NOCT
(Nominal Operating Cell Temperature): lrradiance 800W/m2 , Ambient Temperature 20 'C, Spectra at AMl.5, Wind at l m/S
|
|
|
|
|
|
|||||
Product Details
GLASS
Anti-reflective glass
Service life is as long as 25 years
Module efficiency is increased by 2%
Service life is as long as 25 years
Module efficiency is increased by 2%
Solar Cell
tier 1,PERC/HJT/N Type/
TOPCON
technology,highest power,10% more watt than others
Frame or F rameless
35mm 40mm Anodized Aluminium Alloy
Black/Silver Color Optional
Black/Silver Color Optional
Junction Box
IP 68 rated Waterproof
Innovative Full-Glue-Filled
Portrait/Landscape Length Optional
Innovative Full-Glue-Filled
Portrait/Landscape Length Optional
Compatible MC4
MC4 Compatible /MC4 EVO2/TS4*
500N Tensile Strength
Female/Male/Fuse
500N Tensile Strength
Female/Male/Fuse
Label
Waterproof Customized Label
OEM with your Logo
Professional Silver Color
OEM with your Logo
Professional Silver Color
