Quick Details
-
Thermal Conductivity:
-
0.135
-
Thickness:
-
6/10/15/20/25/30/40/50 Mm
-
Width:
-
300/600/1000mm
-
Length:
-
600/900/1200mm
-
Working Temperature:
-
1800-2000
-
Shrinkage (1800℉, 3h):
-
1.1
-
Place of Origin:
-
Henan, China
-
Model Number:
-
Standard
-
Brand Name:
-
STA
-
Size:
-
Customer's Requirements
-
Color:
-
White
-
Certificate:
-
ISO9001:2008
-
Raw material:
-
Ceramic Fiber Bulk
-
Density:
-
1000-1700kg/m3
-
Package:
-
Customers'requirements
-
Useage:
-
Heat Inslution
-
Other application:
-
High Heat Equipments
-
Name:
-
2000C Zirconia Ceramic fiber Rigid Plates
Quick Details
-
Chemical Composition:
-
AL2O3+SIO2
-
Ultimate Strength (≥ MPa):
-
0.5
-
Fiber Diameter:
-
3-5um
-
Thermal Conductivity:
-
0.135
-
Thickness:
-
6/10/15/20/25/30/40/50 Mm
-
Width:
-
300/600/1000mm
-
Length:
-
600/900/1200mm
-
Working Temperature:
-
1800-2000
-
Shrinkage (1800℉, 3h):
-
1.1
-
Place of Origin:
-
Henan, China
-
Model Number:
-
Standard
-
Brand Name:
-
STA
-
Size:
-
Customer's Requirements
-
Color:
-
White
-
Certificate:
-
ISO9001:2008
-
Raw material:
-
Ceramic Fiber Bulk
-
Density:
-
1000-1700kg/m3
-
Package:
-
Customers'requirements
-
Useage:
-
Heat Inslution
-
Other application:
-
High Heat Equipments
-
Name:
-
2000C Zirconia Ceramic fiber Rigid Plates
2000 C Zirconia Ceramic fiber Rigid Plates
Product Introduction:
ceramic fiber board is a lightweight refractory material processed with alumina-silica fibers for applications at temperatures up to 1430C. it manufactured and designed for the thermal applications requesting high demands on rigidity, the thermal insulation properties and abrasion resistance of ceramic fiber board have been further improved due to the higher density. Ceramic fiber board is a vacuum formed product that resists higher gas velocities than ceramic fiber blanket. It is ideal for furnace, boiler duct and stack lining thanks to its low thermal conductivity and low heat storage, which makes the shorter cycles times and quicker access for maintenance in the industrial furnaces possible.
Now we have got approval of ISO9001:2000,and got many certificates like CE ,SASO,SGS and so on ,our insulation products have been selling to Germany ,UK, Italy, USA, Australia, Japan, Koran ,Turkey ,Israel, UAE ,Saudi Arabia, India ,Sweden ,Poland ,Argentina, Malaysia ,Philippines and other 30 countries.
Now we can produce new produt: Zirconia Ceramic fiber Plates,and the temperature can be 2000 C
Features
1.Low thermal conductivity
2.Low thermal capacity
3.Good thermal shock resistance
4.Flexible and tearing resistance
5.No asbestos and anti-corrosive
6.Good electric and sound insulation
7.Good mechanical working performance
8.Even thickness and density
Physical and chemical composition
|
Item
Type Name |
Standard type |
High purity type |
High-alumina type |
Zirconia contenting type |
||
|
STD |
HP |
HA |
ZA-1 |
ZA-2 |
||
|
Color |
White |
White |
White |
White |
||
|
Classification temperature( ℃ ) |
1100 |
1260 |
1350 |
1400 |
||
|
Maximum operating temperature ( ℃) |
1000 |
1100 |
1200 |
1300 |
1350 |
|
|
Bulk density(Kg/m3 )+/-15% |
260 - 800 |
260 - 800 |
260 - 800 |
260 - 800 |
||
|
Reheating linear shrinkage(Bulk density<260Kg/m3>) |
1100 ℃ x 24h </= 4 |
1260 ℃ x 24h </= 4 |
1350 ℃ x 24h </= 4 |
1400 ℃ x 24h </= 4 |
||
|
Thermal conductivity(w/m.k) ( Bulk density<260Kg/m3>) |
1000 ℃ 0.20 |
1000 ℃ 0.18 |
1000 ℃ 0.19 |
1000 ℃ 0.19 |
||
Pictures showing:
Generally, our warranty is one year. Within the warranty period, we can offer technique support, Feedback to you within 12 hours and help you to settle your problem controller freely.
Q: What's the payment term?
A: T/T, L/C , Western Union and other payment terms could be negotiated.
Q: Do you accept customization service?
A: Yes, of course, we can not only offer standard size ceramic fiber products , but also customized products according to your request. Don't hesitate to tell us your requirement s , we will try our best to meet your needs.
Q: Can we visit your factory before order?
A: Yes, we warmly welcome and sincerely invite you and your team to visit our factory, we will help to arrange hotel and pick up you from A irport.
Q: How about the packing, is it safely protected during transportation?
A: Our ceramic fiber products are packed by standard export carton box for outside package and foam for inner package, it won't be damaged. We've delivered many ceramic goods abroad by S ea or A ir without damage.
