Quick Details
-
Application:
-
Apartment
-
Design Style:
-
Modern
-
Type:
-
quick stage scaffolding
-
Place of Origin:
-
Tianjin, China
-
Brand Name:
-
ADTO
-
Model Number:
-
Kwikstage scaffolding
-
Product name:
-
Kwikstage Diagonal Brace
-
Thickness:
-
48.3x3.2mm
-
Standard Material:
-
Q235 Q345
-
Certificate:
-
AS/NZS 1576/1577
-
Surface finish:
-
painted or galvanized
-
Advantage:
-
Durable, Stable, Skid-proof, Antirust, Easy to assemble & Dismantle
-
Main market:
-
Australian/South Africa/Fiji
-
Length:
-
3.6m/3.2m/2.7m/2.1m/1.7m
-
Packing:
-
Steel pallet
Quick Details
-
Warranty:
-
3 years
-
After-sale Service:
-
Online technical support
-
Project Solution Capability:
-
total solution for projects, Cross Categories Consolidation, Others
-
Application:
-
Apartment
-
Design Style:
-
Modern
-
Type:
-
quick stage scaffolding
-
Place of Origin:
-
Tianjin, China
-
Brand Name:
-
ADTO
-
Model Number:
-
Kwikstage scaffolding
-
Product name:
-
Kwikstage Diagonal Brace
-
Thickness:
-
48.3x3.2mm
-
Standard Material:
-
Q235 Q345
-
Certificate:
-
AS/NZS 1576/1577
-
Surface finish:
-
painted or galvanized
-
Advantage:
-
Durable, Stable, Skid-proof, Antirust, Easy to assemble & Dismantle
-
Main market:
-
Australian/South Africa/Fiji
-
Length:
-
3.6m/3.2m/2.7m/2.1m/1.7m
-
Packing:
-
Steel pallet
Product Description
Kwikstage scaffolding can be fastened once connected, so it is also called quickstage scaffolding system due to its speedy installation. Kwikstage Scaffolding is the one of the best scaffolding systems, reliable in Australia for its flexibility, strength and easy of installation.
This scaffolding system saves erection and dismantling time, reducing labour costs and creating time for what matters most –getting the job done!
This scaffolding system saves erection and dismantling time, reducing labour costs and creating time for what matters most –getting the job done!
Main Components
|
kwikstage standard
|
|
|
|
Material
|
Q235, 48.3*4mm
|
|
|
Length
|
0.5m, 1.0m, 1.5m, 2.0m, 2.5m, 3.0m
|
|
|
Surface finish
|
Painted/Galvanized
|
|
|
Standard
|
AS/NZS 1576
|
|
|
kwikstage Ledger
|
|
|
|
Material
|
Q235, 48.3*3.2mm
|
|
|
Length
|
0.5m, 0.7m, 0.8m, 1.0m, 1.2m, 1.8m, 2.4m, 3.0m
|
|
|
Surface finish
|
Painted/Galvanized
|
|
|
Standard
|
AS/NZS 1576
|
|
|
kwikstage Transom
|
|
|
|
Material
|
Q235, 50*50*5mm
|
|
|
Length
|
0.5m, 0.7m, 0.8m, 1.0m, 1.2m, 1.8m, 2.4m
|
|
|
Surface finish
|
Painted/Galvanized
|
|
|
Standard
|
AS/NZS 1576
|
|
|
kwikstage Diagonal Brace
|
|
|
|
Material
|
Q235, 48.3*3.2mm
|
|
|
Length
|
1.7m, 2.1m, 2.7m, 3.2m, 3.6m
|
|
|
Surface finish
|
Painted/Galvanized
|
|
|
Standard
|
AS/NZS 1577
|
|
|
kwikstage Tie Bar
|
|
|
|
Material
|
Q235, 40*40*4mm
|
|
|
Length
|
0.5m, 0.7m, 1.0m, 1.2m, 1.8m, 2.4m
|
|
|
Surface finish
|
Painted/Galvanized
|
|
|
Standard
|
AS/NZS 1577
|
|
|
Kwikstage Steel Board
|
|
|
|
Material
|
Q235, 230*63mm
|
|
|
Length
|
0.54m, 0.74m, 1.03m, 1.25m, 1.81m, 2.42m, 3.07m
|
|
|
Surface finish
|
Painted/Galvanized
|
|
|
Standard
|
AS/NZS 1577
|
|
Accessories
Features
a)
Durability
: Kwikstage scaffold is made of tough material and provides long-term benefits.
b) Adaptability : It is adaptable to different construction sites and all types of buildings.
c) Increased productivity : it can sustain many workers at the same time, thereby increasing productivity.
d) Lower maintenance costs : It does not require costly maintenance.
e) No loose fittings : the wedgelock system without any screws or nuts
f) Labor saving : it can be erected and dismantled easily and fast.
b) Adaptability : It is adaptable to different construction sites and all types of buildings.
c) Increased productivity : it can sustain many workers at the same time, thereby increasing productivity.
d) Lower maintenance costs : It does not require costly maintenance.
e) No loose fittings : the wedgelock system without any screws or nuts
f) Labor saving : it can be erected and dismantled easily and fast.
