MC series pulse cloth bag dust collector is a single type baghouse dust collector. It adopts circular filter bag, self-contained air ventilation system with pulse injection ash cleaning mode, which has advantages of high dust removal efficiency, good ash cleaning effect, low operation resistance, long service life of filter bag, simple maintenance and stable operation, etc
.
- Product Details
- {{item.text}}
Quick Details
-
Video outgoing:
-
Provided
-
Product name:
-
Pulse cloth bag filter Boiler dust catcher
-
Material:
-
Carbon Steel
-
Main function:
-
Waste Gas treatment
-
Structure:
-
Advanced
-
Keyword:
-
dedusting
Quick Details
-
Place of Origin:
-
HEB
-
Brand Name:
-
XINTIAN
-
Weight:
-
700 kg
-
Video outgoing:
-
Provided
-
Product name:
-
Pulse cloth bag filter Boiler dust catcher
-
Material:
-
Carbon Steel
-
Main function:
-
Waste Gas treatment
-
Structure:
-
Advanced
-
Keyword:
-
dedusting
Products Description
Baghouse dust collector
Product Type
|
Equipment Model
|
|
HMC-24
|
HMC-32
|
HMC-36
|
HMC-48
|
HMC-64
|
HMC-80
|
||||||
|
Total Filtration Area m²
|
|
20
|
25
|
30
|
40
|
50
|
64
|
||||||
|
Filtration Velocity m/min
|
|
1.0-2.0
|
|
|
|
|
|
||||||
|
Air Volume m³/h
|
|
1200-2400
|
1500-3000
|
1800-3600
|
2400-4800
|
3000-6000
|
3840-7680
|
||||||
|
Quantity of Filter Bag
|
|
24
|
32
|
36
|
48
|
64
|
80
|
||||||
|
Specification and Material of Filter Bag
|
|
130*2000mm
|
|
|
|
|
|
||||||
|
Air Outlet Dust Concentration mg/m³
|
|
≤30
|
|
|
|
|
|
||||||
|
Beard Negative Pressure Pa
|
|
5000
|
|
|
|
|
|
||||||
|
Equipment Running Resistant Pa
|
|
800-1200
|
|
|
|
|
|
||||||
|
Injection Pressure Mpa
|
|
0.4-0.6
|
|
|
|
|
|
||||||
|
Electromagnetic
Pulse Valve
|
Specification
|
DMF-Z-25(G1")
|
|
|
|
|
|
||||||
|
|
quantity
|
4
|
4
|
6
|
6
|
8
|
8
|
||||||
|
Induced Draft Fan Model
|
|
4-72-2.8A
|
4-72-3.2A
|
4-72-3.6A
|
4-72-3.6A
|
4-72-4A
|
4-72-4.5A
|
||||||
|
Power of Motor
|
|
1.5kw
|
2.2kw
|
3kw
|
4kw
|
5.5kw
|
7.5kw
|
||||||
Baghouse dust collectors may be considered a thing of the past, but in reality, they’re just as relevant and needed in today’s industries as they were years ago. S.R.D. Dust Collectors’ baghouse dust collectors are most effective when the particulate is larger and the loading is extreme.
Bag repair and replacement can be carried out in separate rooms without stopping the system fan and under normal operating conditions of the system. Filter bag mouth with elastic ring, good sealing performance, firm and reliable. The filter bag keel adopts the polygonal shape, which reduces the friction between the bag and the keel, prolongs the life of the bag, and is easy to unload the bag.
Customer Review
Company introduction
Botou Xintian Environmental Protection Equipment Co., Ltd has a superior geographical position, West 106 National Highway, North Shihuang Expressway, East 104 National Highway, Jingfu Expressway, BeijingShanghai Railway, Highway and Railway crisscross, and the traffic is very convenient. The lo「mation of traffic network provides a time guarantee for the transportation and after-sales service of products.
Our Services
FAQ
Q1: Whether your equipment have passed some international standard?
A1: Now the quality of our shot blasting machine has met ISO9001 ISO14001 CE international standard
Q2: How long is your equipment warranty?
A2: General the warranty is one year (except quick-wear spare parts)
Q3: Whether your company can supply installation?
A3: Online or On-site installation.
Q4: How long is your delivery time ?
A4: Generally it is within 7 days if the goods are in stock.or it is 10-50days if the goods are not in stock,it is according to quantity
Q5: What capacity of we can supply?
A5: We can as your needs to professional design
