AC Compressor Universal Control Board Inverter Air Conditioner System PCB Board
AC Compressor Universal Control Board Inverter Air Conditioner System PCB Board Specification
| Product Name | AC Compressor Universal Control Board Inverter Air Conditioner System PCB Board |
| Type | Rigid |
| Material | FR4, CEM1, CEM3, High Frequency Board, |
| Layer | 1,2,4,6...20Layer |
|
Shape |
Retangular, Round, Slots, Cutouts, Complex, Irregular |
| Cutting | Shear, V-score, Tab-routed |
| Board Thickness | 0.2-4mm, regular 1.6mm |
| Copper Thickness | 0.5-4oz, regular 1oz |
| Solder Mask | Green, Red, Blue, Yellow, etc. |
| Silk Screen | White, Black, etc. |
| Silk Screen Min Line Width | 0.006" or 0.15mm |
| Min Trace/Gap | 0.1mm or 4mils |
| Min Drill Hole Diameter | 0.01",0.25mm or 10mils |
| Surface Finish | HASL, ENIG, OSP, etc. |
Medical Electronic PCB Board we have prodced are mainly used in wearable medical area. All the products must meet ISO9001 CE etc. certification with high quality sodering for wires and no finger print.
Main Products
AC Compressor Universal Control Board Inverter Air Conditioner System PCB Board Certifications
Dalian JY Eletronic Co., Ltd
was established in 2002. We mainly offer
High-Precision Single-Side, Souble-Side, Multi-layer Printed Circuit Boards, LED Aluminium Printed Circuit Board, Customers Components Procurement and
PCB Assembly
(SMT) Business
.
Now the production capacity of our factory has reached 600,000 square meters annually. And our products apply far and wide in many fields such as communication, computer, mobile phone, eletronic equipment and electrical appliance.
We established an assembly line in 2010, all the assembly machines were purchased from Pnansonic, which can assemble the components of 0201. The production capacity of the PCBA are 2,000,000 points per day.
Drill is very important, so we have a perfect drill management area, and a machine 24 hours polished to ensure the quality of the drill bit.
Now we have been a factory which can provide one-stop service, from the PCB production, the components purchasing to the components assemble.
