Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
EVS
-
Model Number:
-
PCL-HE01
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
26500mm*2200mm*2250mm
-
Weight:
-
13500 KG
-
Product name:
-
Paper folding machine
-
Advantage:
-
Eco-friendly
-
After Warranty Service:
-
Online support
-
After-sales Service Provided:
-
After-sales Service
-
Speed:
-
100-120 Pcs/min
Quick Details
-
Machine Type:
-
Bag Forming Machine
-
Bag Type:
-
Patch Bag
-
Material:
-
Paper
-
Place of Origin:
-
China
-
Brand Name:
-
EVS
-
Model Number:
-
PCL-HE01
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
26500mm*2200mm*2250mm
-
Weight:
-
13500 KG
-
Product name:
-
Paper folding machine
-
Advantage:
-
Eco-friendly
-
After Warranty Service:
-
Online support
-
After-sales Service Provided:
-
After-sales Service
-
Speed:
-
100-120 Pcs/min
Specification
|
Material:
|
Kraft Paper /Honeycomb Paper mailer envelope machine production line
|
|
|
|
|||
|
Unwinding Width
|
≦1500 mm
|
Unwinding Diameter
|
≦1200 mm
|
|
|||
|
Speed of Making Bag
|
30-60 units /min
|
|
|
|
|||
|
Machine Speed
|
70 /min
|
|
|
|
|||
|
Bag Width
|
≦800 mm
|
Bag Length
|
700 mm
|
|
|||
|
Unwinding Shaft
|
3 inches Air Swelling Shaft
|
|
|
|
|||
|
Voltage of Power Supply
|
22V-380V,50HZ
|
|
|
|
|||
|
Total Power
|
25 KW
|
|
|
|
|||
|
Machine Weight
|
13.5 T
|
|
|
|
|||
|
Appearance Color of Machine
|
White Plus Gray＆Yellow
|
|
|
|
|||
|
Machine Dimension
|
26500mm*2200mm*2250mm
|
|
|
|
|||
|
12 mm thick Steel Slates for The Whole Machine (The machine is plastic sprayed.)
|
|
|
|
|
|||
|
Air Supply
|
Auxiliary Device
|
|
|
|
|||
