Quick Details
-
Warranty:
-
1 year
-
electric motor powe:
-
3000w
-
Certification:
-
ISO9001
Quick Details
-
Displacement (ml):
-
150cc
-
Place of Origin:
-
Chongqing, China
-
Brand Name:
-
Zongshen
-
Warranty:
-
1 year
-
electric motor powe:
-
3000w
-
Certification:
-
ISO9001
Power section Technical parameters Power Technology Parameter
Rated voltage VDC (Rated. Voltage) 60
Drive current limit ADC (Current limit) 85 ± 2
Drive motor rated power W (Rated Voltage) 1500
Drive motor rated speed rpm (rated speed) 4000 ± 200r / min
Rated current A (Rated Current) ≤ 33
Driving motor maximum efficiency% (Max. Efficiency) ≥90%
Engine displacement
Pure oil maximum power kw (Max. Power) (fuel consumption) 8.5 (1 ± 10%)] / 7500 (1 ± 5%)
Pure oil maximum torque (output shaft) Max.Torque (N.m / r / min) 11 (1 ± 10%)] / 6000 (1 ± 5%)
Pure oil fuel minimum consumption rate g / kw.h (fuel consumption) ≤ 354
Parallel maximum power kw (Max. Power) (fuel consumption) 9 (1 ± 10%)] / 5000 (1 ± 5%)
Parallel maximum output torque (output shaft) N.m (Torque max) 19 (1 ± 10%)] / 3500 (1 ± 5%)
Parallel operation fuel minimum consumption rate g / kw.h (fuel consumption) ≤ 200
Weight Kg (Net Weight) 43
Oil capacity ml (volume of engine oil) 1500
Controller Part Technical Data MCU Technology Parameter
Rated voltage (V)
Rated current (A)
Current limit (A) is 85 ± 2
Undervoltage V (Oprating Voltage) 52 ± 1
we supply the whole set of the hybrid engine which should include following items:
