NULITE R32 WIFI control 10KW 20KW 30KW DC inverter Monobloc Air to Water heat pump

NULITE R32 WIFI control 10KW 20KW 30KW DC inverter Monobloc Air to Water heat pump

FOB Reference Price: Get Latest Price

≥2 Sets

US $1799

≥50 Sets

US $1699

≥100 Sets

US $1599

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Type:: Air Source Heat Pump

Place of Origin:: Guangdong, China

Brand Name:: Nulite

Model Number:: NL-BKDX50-200II/R32

Item:: heat pump water heater

Heating capacity:: 21KW

Voltage:: 220V 50HZ/380v 50Hz

Ambient temperature:: -25C to 43C

Function:: Heating/Hot Water/Cooling

Max Hot Water Temperature:: 60C

Sound Level:: less than 52dB(A)

Refrigerant:: R32

Rated of waterproof:: IPX4

Quick Details

Warranty:: 2 years

Application:: Outdoor, Hotel, Commercial, Household

Power Source:: Electric

Type:: Air Source Heat Pump

Place of Origin:: Guangdong, China

Brand Name:: Nulite

Model Number:: NL-BKDX50-200II/R32

Item:: heat pump water heater

Heating capacity:: 21KW

Voltage:: 220V 50HZ/380v 50Hz

Ambient temperature:: -25C to 43C

Function:: Heating/Hot Water/Cooling

Max Hot Water Temperature:: 60C

Sound Level:: less than 52dB(A)

Refrigerant:: R32

Rated of waterproof:: IPX4

NULITE A+++ ERP CE etc. Heat Pump OEM Manufacturer:

10KW 16KW 21KW 30KW 40KW R32 EVI DC Inverter Monoblock Heat Pump

Nulite BKDX Series(Monoblock):

R32 EVI Full DC Inverter Exhaust Air Heat Pump with RS485 communication interface, Defrosting function, Wifi control function, Double DC fan motors and Low Noise

1. Triple functions: heating, cooling, heating water .
2. Providing different sizes of heating power: 2 kw, 5 kw, 5.5 kw, 8.4 kw, 9.5 kw.
3. Rated heating capacity: 10 kw, 16 kw, 20 kw, 31 kw, 40 kw .
4. The EVI technology is included, that it can be available to work in -25 ℃ .
5. Full DC inverter is beneficial to enhance the performance, accuracy of controlling temperature while is
environmental-friendly.
6. Core components are offered by : Panaonic(Compressor), SWEP(Plate heat exchanger) , Wilo(water pump), ACOL(Expansion Tank).

7. Defrosting function, Smart Phone control Function .
8. Extra powerful from the 3 kw electric heater .
9. Certifications : ISO9001, CE, CB, 35℃A+++/ 55℃A++ erP etc..
10. Providing OEM customization .

Please send me your Enquiry and get the catalogue, or contact me directly in

E-mail: tim@ne01-e.com

Product Description

DC Inverter Compressor

Electric DC Inverter dual-rotor compressor comes from Pana-sonic with heating/cooling/hot water.
Saving your energy : input power is changed with the exterior context.

As Quiet As Library

DC Fan(s) are designed with the unique structure so as to low down the operating decibel. Inreturn, it’s a good quality sleep.

Warm you up in -25°C, nice and cool in 43°C

Wide range of Ambient Temperature( -25° to 43° ) and Water Outlet Temperature( 12° to 60° ) : EVI technology guards the heat pump functioning well even in negative 25 degree. Meanwhile, cooling function expel hot in summertimes.

Defrosting Function

Prevented frost from building up further or functioned before heat pump start to work.The defrosting function will kick-off once there's a certain level of frost remaining on the evaporator was detected by the senor.

Panel control + Wifi control + RS485 communication interface

Easy & convenient to use : Download Tuya Smart to use phone/Pad to take control temperature in your home once connecting with the same WIFI .

Straightforward panel interface : Using iconic to illustrate features which is beneficial to fasting learning of how to control the heat pump especially for the elderly.

With RS485 interface: Realize the communication externally.

3KW electric backup heater

BKDX has integrated with a 3kw inbuilt electric backup heater for defrosting & back up energy supply purposes according to the actual situation that if operate automatically.

Product Paraments

	NL-BKDX30-95II/R32	NL-BKDX40-150II/R32	NL-BKDX50-200II/R32	BKDX80-300II/R32
Rated heating capacity (KW)	2.8-10	3.8-16	5.5-21	7.2-31
Rated hot water capacity (KW)	2.5-9.5	3.5-15.5	4.5-20	7-30.5
Rated cooling capacity (KW)	2.5-7.5	3.8-11	4.8-14.5	7-23.5
Heating power consumption(KW)	1-3.2	1.5-5	2-5.5	3.2-8.4
Voltage(V/Hz)	220V-240V~Inverter-1N	220V-240V~Inverter-1N/380V-415V~Inverter-3N			380V-415V~Inverter-3N
Rated output water temperature(℃)	Hot water:55℃/Heating：55℃/Cooling：12℃
Refrigeration	R32
Compressor	Japanese Panasonic brand with Inverter + EVI technology
Plate heat exchange	Sweden SWEP Plate heat exchanger
Fan	Full DC fan motor
Auxiliary Element(KW)	3
Operation ambient temperature(℃)	-25℃-43℃
ErP Energy class	35℃A+++/ 55℃A++	35℃A+++/ 55℃A++	35℃A+++/ 55℃A++	35℃A+++/ 55℃A++
20"GP container loading(pcs)	48	24	24	/
40"HQ container loading(pcs)	96	48	48	/
