Quick Details
-
Voltage:
-
380-440 V
-
Power:
-
50-20000 KW
-
Dimension(L*W*H):
-
Customized
-
Weight (KG):
-
38
-
Name:
-
Small Rebar Production Line
-
Model:
-
H250-3
-
kw:
-
180
-
M/S:
-
1.8-2.5
-
T/SHIFT:
-
3-6
-
ROLLING CAPACITY:
-
30
-
FEED SECTION:
-
50*50
-
WEIGHT:
-
27.5
-
ROLLING SPECIFICATION:
-
<34<100*10<40
-
Notes:
-
thread flat steel angle steel
Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Hongteng
-
Marketing Type:
-
New Product 2022
-
Voltage:
-
380-440 V
-
Power:
-
50-20000 KW
-
Dimension(L*W*H):
-
Customized
-
Weight (KG):
-
38
-
Name:
-
Small Rebar Production Line
-
Model:
-
H250-3
-
kw:
-
180
-
M/S:
-
1.8-2.5
-
T/SHIFT:
-
3-6
-
ROLLING CAPACITY:
-
30
-
FEED SECTION:
-
50*50
-
WEIGHT:
-
27.5
-
ROLLING SPECIFICATION:
-
<34<100*10<40
-
Notes:
-
thread flat steel angle steel
If you want to produce building rebar, steel bars, contact us!
We can provide you with equipment, free technology and teach you how to produce steel bar.
Product Show
1. 1-5t/hour steel bar production line, final bar size range is 8-32 mm,most use for build for small rolling mill.we have half-automatic/fully automatic steel bar production line machinery.we can also design machinery under customer's invest.so the more of your suggestion will be best for us.
2. The raw material can be scrap metal or billet.For capacity 1-5 t ,our suggestion billet size can be 40*40mm,50*50mm,60*60mm, 1000 - 6000 mm long,under this size in production will be the smallest machinery investment.
3. The whole steel bar production line new need heating furnace for billet, the heating furnace can use gas/electric/oil ,we can under your requirement design the whole line.
4. About the cooling bed .you can use or not both all right.
5. We will supply the whole line installation & debugging service,till machine to normal production.
6. The more of your detail requriement,will help us alot to design the suitable steel bar production line for you.
7. Welcome to visit us and have a face to face negociation.
Our company supply all kinds of steel wire /rebar/bar production line productivity.
two types Steel production line:
1. Raw material is scrap steel iron
melting→Continuous casting machine→Hot rolling mill→Cutting machine→cooling bed→ packing table
2. Raw material is steel billet
Billet heating furnace→Hot rolling mill→Cutting machine→ cooling bed→ packing table
Project site
Main features of induction reheating furnace for rebar production line:
1.Temperature ability: whole billet heated to 1100 ℃;
2. the mean temperature ability: through the induction heating furnace, ensure the temperature of the billet heating uniformity is better than before the state of nature;
3. intermediate frequency power supply
A) according to the technical index, increased within 1 minute from 800 ℃ to 1100 ℃, the heating power required to take the whole of 5700 kw.
B) the power consumption theoretical calculation of tons of billet is 38 degrees (such as heating, 200 degrees Celsius, tons of billet power consumption is 25 degrees)
Product Advantages
1. The small production capacity of 1t-15t/h is the standard product of our company.
2. That diameter of the steel bar of the final product: 6.5-32mm, the square steel bar: 100*100, 150*150, and the length: 3000-6000mm
3. Adopt numerical control system, that production is divided into six zone: melting zone, casting zone, heating zone, rolling zone, cooling zone and collecting zone
4. Provide overall solution and after-sales guarantee
--Provide plant design, proposal, manufacturing, shipping, installation and commissioning services
-Provide factory building design, overall equipment layout, rolling mill process design, electrical circuit layout and other services.
---Dispatch technicians to provide installation services after the machine arrives until the customer is satisfied
-Long-term technical support, long-term machine warranty
|
Specification and Technical Parameter
|
|
|
|
|
||||
|
Model
|
Power (KW)
|
Rolling Speed(M/S)
|
Feed section (MM)
|
Rolling specification
|
||||
|
H200-2
|
90
|
1.5
|
30*30
|
Ø10-16
|
||||
|
H220-2
|
95
|
1.5-2
|
40*40
|
Ø10-24
|
||||
|
H250-3
|
180
|
1.8-2.5
|
50*50
|
Ø8-32
|
||||
|
H250-4
|
315/240
|
2.5-4
|
60*60
|
Ø8-32
|
||||
|
H250-5
|
500
|
2.5-5
|
50*50
|
Ø6.5-32
|
||||
|
H280-5
|
630
|
2-2.5
|
70*70
|
Ø6.5-32
|
||||
|
H300-5
|
680
|
2-2.5
|
90*90
|
Ø6.5-32
|
||||
|
H350-5
|
800
|
2-2.5
|
90*90
|
Ø6.5-32
|
||||
