- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
Boyu
-
Model Number:
-
SKL-7
-
Usage:
-
Heavy Duty
-
Structure:
-
F Clamp
-
Product name:
-
stringing equipment tools aluminum alloy self gripping come along clam
-
Conductor size:
-
25-70mm2
-
Rated load:
-
7kN
-
Max.opening:
-
14mm
-
Weight:
-
1.0kg
Quick Details
-
Measurement system:
-
INCH
-
Material:
-
Aluminium
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Boyu
-
Model Number:
-
SKL-7
-
Usage:
-
Heavy Duty
-
Structure:
-
F Clamp
-
Product name:
-
stringing equipment tools aluminum alloy self gripping come along clam
-
Conductor size:
-
25-70mm2
-
Rated load:
-
7kN
-
Max.opening:
-
14mm
-
Weight:
-
1.0kg
stringing equipment tools aluminum alloy self gripping come along clamps
The self gripping clamps can be use to anchor and to string conductor (aluminum, ACSR, copper...) and steel rope. The body is made of high strength hot forged steel or Aluminum, in order to minimize the ratio between weight and working load.
For Conductor
|
Model |
Conductor size (mm2) |
Rated load (kN) |
Max. opening (mm) |
Weight (kg) |
|
SKL-7 |
25~70 |
7 |
14 |
1.0 |
|
SKL-15 |
95~120 |
15 |
18 |
1.4 |
|
SKL-25 |
150~240 |
25 |
22.5 |
3.0 |
|
SKL-40 |
300~400 |
40 |
32 |
4.0 |
|
SKL-50 |
500~630 |
50 |
36 |
6.6 |
|
SKL-40G |
400 |
40 |
32 |
4.3 |
|
SKL-50GA |
500 |
50 |
34 |
7.0 |
|
SKL-50GB |
630 |
50 |
36 |
7.3 |
|
SKL-60G |
720 |
60 |
38 |
9.2 |
|
SKL-70G |
900 |
70 |
42 |
14 |
|
SKL-80G |
1000 |
80 |
45 |
18 |
|
SKL-80GA |
1200 |
80 |
48 |
18 |
G-with protection hook device
Jiangsu Province Yixing Boyu Electric Power Industry Company is located in west side of the beautiful and fertile Taihu Lake.
Our company is high-tech enterprise of Jiangsu province having six patents, including two invention patents. Our company has a total area of 42800 square meters, having formed four series products:
1: Electric power construction tools
2: Nonmetallic galvanized the production equipment (Achieved high-tech products)
3: Numerical control machine
4: Low voltage no power-arc furnace compensation system
History
Established in 199 4 , Yixing city Boyu power machinery Co., LTD
In 2001 the company passed ISO9001 certification, and obtain the AAA certificate
In 2006 attains the Wuxi city contract trustworthiness enterprise, also achieved famous brand product in Wuxi city
In 2007 attains the high-tech enterprise of Jiangsu province, also achieved brand-name products in Jiangsu province
In 2009 reworded significant achievement in Wuxi city
In 2010 Boyu cooperated with Germany famous Caesar Company establishing the Boset brand
In 2010 achieved the national ministry of science and technology innovation in science and technology project.
To November 8, 2010, Boyu enterprise has already sell puller and tension equipment (excluding mobile ground grinding) nearly 4000 sets. Our products are sold well in Sudan, Kenya, Angola, Pakistan, Burma, India, Mexico,Germany.
