Quick Details
-
Marketing Type:
-
New Product 2022
-
Core Components:
-
laser source
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
HaiYi
-
Dimension(L*W*H):
-
62*47*29cm
-
Year:
-
2024
-
Weight (KG):
-
23 KG
-
After-sales Service Provided:
-
Online technical support
-
Drawing graphics selection:
-
Line/rectangle
-
Laser wavelength:
-
1064nm
-
Certification:
-
CE,ISO9001
Quick Details
-
Power:
-
100W
-
Laser Type:
-
Pulse
-
Laser Source Brand:
-
GZ
-
Marketing Type:
-
New Product 2022
-
Core Components:
-
laser source
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
HaiYi
-
Dimension(L*W*H):
-
62*47*29cm
-
Year:
-
2024
-
Weight (KG):
-
23 KG
-
After-sales Service Provided:
-
Online technical support
-
Drawing graphics selection:
-
Line/rectangle
-
Laser wavelength:
-
1064nm
-
Certification:
-
CE,ISO9001
PRODUCT
APPLICATION
Widely used for metal rust removal, paint removal, oil grease dirt removal, etc.
It can be applied to industry rust removal with high efficiency, by using CW laser cleaning.
Industry Applications
1. For aerospace industry: cleaning before and after aluminum alloy welding; cleaning of titanium alloy before and after welding; Aircraft radar layer repair laser cleaning.
2. For shipbuilding industry: laser cleaning before and after welding in shipbuilding; Laser cleaning of surface before coating; Ship maintenance training.
3. For rail transit industry: stainless steel train manufacturing and cleaning; Aluminum alloy train manufacturing laser cleaning; Rail transit equipment maintenance and laser cleaning.
4. For automobile manufacturing industry: cleaning of galvanized sheet before welding; Cleaning of Al alloy before and after welding.
5. For steel manufacturing industry: derusting of steel surface; derusting of cold rolled sheet surface.
TECHNICAL PARAMETERS
|
Model
|
HY-CH01
|
|
HY-CR01
|
|
||
|
Laser Type
|
CW Laser source
|
|
Pulse Laser Source
|
|
||
|
Max laser power
|
1000/1500/2000W
|
3000W
|
100W
|
200/500W
|
||
|
Scanning speed
|
6000mm/S
|
|
6000mm/S
|
|
||
|
Max scanning width
|
0-150MM
|
|
0-110mm
|
0-175mm
|
||
|
Clean area
|
0.4-0.8㎡/min
|
|
0.2-0.5㎡/min
|
|
||
|
Cooling system
|
Water Chiller
|
|
Air Cooling
|
Water Chiller
|
||
|
Power supply
|
220V/50HZ&60HZ
|
380V/50HZ&60HZ
|
220V/50HZ
|
220V/50HZ
|
||
|
Size
|
90*40*70cm
|
90*55*87cm
|
62*47*30cm
|
90*87*100cm
|
||
|
Weight
|
≈120kg (net)
|
≈150kg
|
≈28kg (net)
|
≈270kg
|
||
FEATURES AND ADVANTAGES
1.Non contact cleaning will not damage the part matrix. No chemical cleaning solution, no consumables, safe and environmental protection.
2.The laser cleaning head is lightweight and can be held for a long time. The laser cleaning system is stable and almost maintenance free.
3.High cleaning efficiency and time saving. Red light assists in focusing, and the focusing position can be adjusted according to different field mirrors.
4.Precise cleaning, which can realize selective cleaning in precise position and size.
5.Easy to operate just powered on. Optional for hand-held and automatic cleaning.
