solar panel 1000 watt 500w 490 w 480w 400w 350w solar panel

solar panel 1000 watt 500w 490 w 480w 400w 350w solar panel

FOB Reference Price: Get Latest Price

≥100000 Pieces

US $0.12

≥500000 Pieces

US $0.1

≥1000000 Pieces

US $0.09

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Warranty:: 25years, 25 Years Output Power Guarantee

Brand Name:: Rosen/OEM

Model Number:: RS500M-96

Place of Origin:: Anhui, China

Panel Dimensions:: 2176*1096*35mm etc

Product name:: Mono 500watt Solar Panels

Junction Box:: IP68

Solar cell:: 10/12BB Mono166/182/210 Tier 1

Glass:: 3.2mm Tempered Low Iron

TPT back sheet:: Black/White Backsheet

OEM:: Avaliable

Application:: Lithium Energy Storage System

Certificate:: TUV/IEC61215/IEC61730/CEC/CE/PID/ISO

Quick Details

Cell size:: 182mmx182mm

Type:: PERC, Half Cell, Bifacial, All Black, N-TYPE, TOPCON, BIPV

Panel Efficiency:: 22% up

Warranty:: 25years, 25 Years Output Power Guarantee

Brand Name:: Rosen/OEM

Model Number:: RS500M-96

Place of Origin:: Anhui, China

Panel Dimensions:: 2176*1096*35mm etc

Product name:: Mono 500watt Solar Panels

Junction Box:: IP68

Solar cell:: 10/12BB Mono166/182/210 Tier 1

Glass:: 3.2mm Tempered Low Iron

TPT back sheet:: Black/White Backsheet

OEM:: Avaliable

Application:: Lithium Energy Storage System

Certificate:: TUV/IEC61215/IEC61730/CEC/CE/PID/ISO

Panels Description

Technical Specification Data

Rosen Solar, with more than 4 automatic lamination lines, are professional manufacturer of solar panels with wide power range from 5w to 300W, 450W, 550W, 600W, 650W, 680W, 700W, 800W etc. Solar panels, like PERC, N-Type TOPCON, HJT, Shingle types etc and bifacial/double glass, single glass, full black, black frame, and frameless half cell panels Mono and Polycrystaline panels, are all available in China and Europe stock.

Tier 1 panels brands like JA, Jinko etc are available too. OEM and ODM service acceptable with the min one pallet.

We have all certificates like TUV, CE, ISO, IEC etc, And technicians will provide manuals, and installation CAD SKETCH designs for roof or ground installation.

Model	RS400M-96	RS460M-96	RS480M-96	RS490M-96	RS500M-96
Rated Maximum Power at STC	400W	460W	480W	490W	500W
Open Circuit Voltage(Voc/V)	58.50	58.75	58.89	58.92	58.95
Maximum Power Voltage(Vmp/V)	47.78	48.01	48.35	48.45	48.63
Short Circuit Current(Isc/A)	9.40	9.78	10.04	10.67	10.87
Maximum Power Current(Imp/A)	9.21	9.59	9.93	10.12	10.28
Module Efficiency	17.17%	17.95%	18.73%	19.12%	19.51%
Standard Test Condition(STC)	Irradiance 1000w/m2, Cell Temperature 25 Centigrade, Air Mass 1.5

Detailed Images

Solar Cells

High efficiency 5BB PV cell Mono
Uniform color
Anti-PID
Germany standard Cell
Full test

Junction box

Conventional standalone edition and engineering custom edition
Quality diode ensures module running safety
IP67 protection level
Heat dissipation
Long service life
