Quick Details
-
Application:
-
industrial instrument
-
Keypad Button Material:
-
PET
-
Material:
-
0.15mm Velvet PET
-
Adhesive:
-
3M467
-
Color:
-
PANTONR&RAL
-
Size:
-
86*35mm
-
Metal dome:
-
Nickel plated Metal Dome
-
Feature:
-
Push Buttons
-
Connector:
-
Female Connector +Housing
-
Technique:
-
Silk Screen Printing
-
Hot sales:
-
Waterproof Membrane Keypad Switch
Quick Details
-
Place of Origin:
-
Liaoning, China
-
Brand Name:
-
Geeton
-
Model Number:
-
GMS-346
-
Application:
-
industrial instrument
-
Keypad Button Material:
-
PET
-
Material:
-
0.15mm Velvet PET
-
Adhesive:
-
3M467
-
Color:
-
PANTONR&RAL
-
Size:
-
86*35mm
-
Metal dome:
-
Nickel plated Metal Dome
-
Feature:
-
Push Buttons
-
Connector:
-
Female Connector +Housing
-
Technique:
-
Silk Screen Printing
-
Hot sales:
-
Waterproof Membrane Keypad Switch
Product Description
NO.1 Waterproof 16 Push Buttons Membrane Keypad Switch
NO.2 16 Keys Membrane Switch Keypad
|
Membrane Switch Performance |
|
|
Electrical Performance |
|
|
Circuit Grade |
35V(DC),100mA,1 W |
|
Loop Resistance |
10Ω - 500Ω(According the trace length and materials to confirm) |
|
Insulation Resistance |
>100MΩ 250V(DC) |
|
Dielectric Resistance |
250VRms(50 - 60Hz/1 min) |
|
Contact C hatter Time |
≤5ms |
|
Service Life |
flat type≥5 million times |
|
tactile type:≥1 million times |
|
|
Mechanical Properties |
|
|
Operating Force |
flat type 57-284g (2-10 Oz) |
|
tactile type 170-397g (6-14 Oz) |
|
|
Switch Stroke |
flat type 0.1 - 0.5mm |
|
tactile type 0.6 - 1.5mm |
|
|
Environmental Parameters |
|
|
Operating Temperature |
-20°C - +80°C |
|
Storage Temperature |
-40°C - +85°C |
|
Humidity |
40°C,90%-95%,240 hours |
NO.3 Recommend Membrane Switch Keypad
NO.4 Membrane Switch Keypad Type
NO.5 Membrane Switch Keypad Application
